13
TQBJ2156
Specifications
█
General
Dimensions (W x H x D) 400 mm x 197 mm x 107 mm
(15
3
/
4
″ x 7
3
/
4
″ x 4
1
/
4
″)
Mass (Weight) 1.9 kg (4.2 lbs)
Operating temperature range
0°C to +40°C (+32°F to +104°F)
Operating humidity range
35% to 80% RH (no condensation)
█
Amplifier section
RMS output power stereo mode
Front Ch (both ch driven)
10 W per channel (8 Ω), 1 kHz, 10% THD
Total RMS power 20 W
█
Tuner, terminals section
Preset memory FM 30 stations
Frequency modulation (FM)
Frequency range
87.90 MHz to 107.90 MHz (200 kHz step)
87.50 MHz to 108.00 MHz (100 kHz step)
Antenna terminals 75 Ω (unbalanced)
█
Disc section
Disc played [8 cm (3″) or 12 cm (5″)]
CD, CD-R/RW (CD-DA, MP3
2
)
Pick up
Wavelength 790 nm (CD)
█
USB section
USB port power WDC OUT 5 V 500 mA
USB standard USB 2.0 full speed
Media file format support MP3 (*.mp3)
Audio support format MP3
2
Sampling frequency 32 kHz, 44.1 kHz, 48 kHz
Audio word size 16 bits
Channel count 2 ch
USB device file system FAT12, FAT16, FAT32
█
Bluetooth
®
section
Version Bluetooth
®
Ver. 2.1 + EDR
Class Class 2
Supported profiles A2DP, AVRCP
Frequency band 2.4 GHz band FH-SS
Operation distance 10 m (33 ft) line of sight
Supported codec SBC
█
Speaker section
Speaker unit(s)
Full range 8 cm (3
1
/
8
″) cone type x 2
Note:
• Specifications are subject to change without notice.
Mass (Weight) and dimensions are approximate.
• Total harmonic distortion is measured by the digital
spectrum analyzer.
1
No device is connected to the USB port before turning to
standby mode.
2
MPEG-1 Layer 3, MPEG-2 Layer 3
Power supply 14AC 120 V, 60 Hz
Power consumption
14 14 W
Power consumption in standby mode
1
(approximate)
With “BLUETOOTH STANDBY” set to “OFF” 0.2 W
With “BLUETOOTH STANDBY” set to “ON” 0.3 W
HC200.PC TQBJ2156 En.fm Page 13 Wednesday, April 4, 2018 8:58 AM
