Push to open the dock.
Insert the suitable dock adapter (not included) for the
iPod/iPhone.
Insert the side of the iPod/iPhone dock adapter with the clips
facing towards you first and then push the opposite side until
it clicks into place.
Connect the iPod/iPhone (not included) firmly.
Be sure to remove the iPod/iPhone from its case.
To remove, simply pull the iPod/iPhone straight out to
disconnect it.
When inserting an iPod/iPhone into the unit, be sure to use
the dock adapter either supplied with the iPod/iPhone or
commercially available from Apple Inc.
When not using the dock, push it back until it locks.
Reduce the volume of the main unit to minimum before
connecting or disconnecting the iPod/iPhone.
•
•
•
Enjoying audio from iPod or iPhone
g Inserting or removing an iPod/iPhone
■ Charging the iPod/iPhone
When iPod/iPhone is being charged in standby mode,
“IPOD CHARGING” is shown on the main unit’s display.
Check iPod/iPhone to see if the battery is fully charged. If you
are not using iPod/iPhone for an extended period of time after
recharging has completed, disconnect it from the main unit as
the battery will be depleted naturally. (Once fully recharged,
additional recharging will not occur.)
•
•
Notes on iPhone:
All phone features can only be controlled by the iPhone’s
touch screen.
The unit does not display incoming calls or the phone status.
The ringtone of incoming call can be heard from the iPhone’s
speaker. When the unit is in iPod/iPhone mode, the ringtone
can also be heard from the unit’s speakers.
The voice of caller cannot be heard on the unit’s speakers.
The user can use the iPhone internal microphone though.
Connecting or disconnecting the iPhone from the unit will not
cancel a call.
There is no Apple Inc. specification that will guarantee the
iPhone responses above. iPhone responses may vary on
new iPhone models or iPhone new software updates.
•
•
•
•
•
•
Play
Press [iPod q/h].
Pause
Press [iPod q/h] or [g].
Skip track
Press [u/t] or [y/i].
Search the current track
Press and hold [u/t] or
[y/i].
Display iPod/iPhone menu/
return to previous menu
Press [iPod MENU] in the play
mode.
(Remote control only)
Select contents from
iPod/iPhone menu
Press [e,r] and then [OK].
(Remote control only)
External unit (continued)
Push!
■ Compatible iPod
Name Memory size
iPod nano 5th generation
(video camera)
8 GB, 16 GB
iPod touch 2nd generation 8 GB, 16 GB, 32 GB,
64 GB
iPod classic 120 GB, 160 GB (2009)
iPod nano 4th generation (video) 8 GB, 16 GB
iPod classic 160 GB (2007)
iPod touch 1st generation 8 GB, 16 GB, 32 GB
iPod nano 3rd generation (video) 4 GB, 8 GB
iPod classic 80 GB
iPod nano 2nd generation
(aluminum)
2 GB, 4 GB, 8 GB
iPod 5th generation (video) 60 GB, 80 GB
iPod 5th generation (video) 30 GB
iPod nano 1st generation 1 GB, 2 GB, 4 GB
iPod 4th generation (colour display) 40 GB, 60 GB
iPod 4th generation (colour display) 20 GB, 30 GB
iPod 4th generation 40 GB
iPod 4th generation 20 GB
iPod mini 4 GB, 6 GB
■ Compatible iPhone
Name Memory size
iPhone 3GS 16 GB, 32 GB
iPhone 3G 8 GB, 16 GB
iPhone 4 GB, 8 GB, 16 GB
Compatibility depends on the software version of the
iPod/iPhone.
•
