16
RQT9731
Specifications
≥ Specifications are subject to change without notice.
Mass and dimensions are approximate.
≥ Total harmonic distortion is measured by a digital spectrum
analyzer.
*1: [SC-HC28DB] When the iPod/iPhone/iPad is not charging
and the dock is closed.
*2: MPEG-1 Layer 3, MPEG-2 Layer 3
∫ GENERAL
Power consumption [SC-HC28DB] 40 W
[SC-HC18] 12 W
Power consumption in standby mode*
1
Approx. 0.2 W
[SC-HC28DB]
Power consumption in standby mode
(With the iPod dock open)
Approx. 0.4 W
Power supply
AC 220 V to 240 V, 50 Hz
Dimensions (WkHkD)
400 mmk213 mmk110 mm
(Min. Depth: 72 mm)
[SC-HC28DB] (Depth when tray open: 134 mm)
Mass [SC-HC28DB] Approx. 2 kg
[SC-HC18] Approx. 1.9 kg
Operating temperature range
0 oC to r40 oC
Operating humidity range
35 % to 80 % RH (no condensation)
∫ AMPLIFIER SECTION
Output power
RMS Output Power Stereo mode
Front Ch (both ch driven)
5 W per channel (6 ≠), 1 kHz, 10 % THD
Total RMS Stereo mode power
10 W
∫ TUNER SECTION
Preset Memory FM 30 stations
Frequency Modulation (FM)
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals
75 ≠ (unbalanced)
∫ [SC-HC28DB] DAB SECTION
DAB memories 20 channels
Frequency Band (Wavelength)
Band III (LOCAL) 10B to 12D
(211.648 MHz to 229.072 MHz)
Band III (ALL BAND III) 5A to 13F
(174.928 MHz to 239.200 MHz)
Sensitivity *BER 4x10
-4
Min Requirement s98 dBm
DAB External Antenna
Terminal F - Connector (75 ≠)
∫ DISC SECTION
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3*
2
)
Pick up
Wavelength 790 nm (CD)
Audio output (Disc)
Number of channels
2 ch (FL, FR)
∫ SPEAKER SYSTEM SECTION
Type
1 way, 1 speaker system (Bass reflex)
Speaker unit(s)
Full range
8cmConetypek1 per channel
Impedance 6 ≠
∫ TERMINAL SECTION
[SC-HC28DB] “IPOD_DOCK” connection
DC OUT 5V2.1AMAX
“IPOD_PORT” connection ([SC-HC28DB]) /
“USB” connection ([SC-HC18])
[SC-HC28DB] DC OUT 5 V 2.1 A MAX
[SC-HC18] DC OUT 5V500mAMAX
USB Standard
USB 2.0 full speed
Media file format support
MP3 (¢.mp3)
USB device file system
FAT12, FAT16, FAT32
