26
RQT0B25
Specifications
§1 When the other connected devices are turned off.
AMPLIFIER SECTION
RMS output power: Dolby Digital Mode
Front ch (L, R ch)
60 W per channel (6 ≠), 1 kHz, 10 % THD
Subwoofer ch
130 W per channel (8 ≠), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power
250 W
TERMINAL SECTION
Digital audio input (TV)
Optical digital input
Optical terminalk1
Sampling frequency
32 kHz, 44.1 kHz, 48 kHz
88.2 kHz, 96 kHz (only LPCM)
Audio format
LPCM, Dolby Digital, DTS Digital Surround
TM
USB Port
For service use only.
GENERAL
Power consumption
Main unit
34 W
Active subwoofer
23 W
In standby condition
Main unit
§1
When “BLUETOOTH STANDBY” is “OFF”
Approx. 0.48 W
When “BLUETOOTH STANDBY” is “ON”
Approx. 3 W
Active subwoofer
Power switch off
Approx. 0.25 W
The wireless link is not activated
Approx. 1.3 W
Power supply
AC 220 V to 240 V, 50 Hz
Dimensions (WkHkD)
Main unit
For table top layout
950 mmk53 mmk110 mm
For wall mounting layout
950 mmk110 mmk57 mm
Active subwoofer
180 mmk408 mmk306 mm
Mass
Main unit
For table top layout
Approx. 2.5 kg
For wall mounting layout
Approx. 2.6 kg
Active subwoofer
Approx. 5.0 kg
Operating temperature range
0
o
C to i40
o
C
Operating humidity range
20 % to 80 % RH (no condensation)
SC-HTB385_EGEB_RQT0B25-B.book 26 ページ ２０１６年３月２９日 火曜日 午前９時３３分
