Panasonic SC-HTB600 User Manual

15
TQBJ2216
3 Drive the screws into the wall.
• Use the measurements indicated below to identify the screwing positions on the wall.
• Leave at least 100 mm of space above of the main unit to allow enough space for fitting the main
unit.
• Be sure to use a level to ensure that both mounting holes are level to each other.
Front view (semi-transparent image)
4 Fit the main unit securely onto the screws.
DO DO NOT
Move the speaker so that the
screw is in this position.
In this position, the speaker will
likely fall if moved to the left or
right.
> 30 mm
Ø7.0 mm - Ø9.4 mm
3.5 mm - 4.5 mm
Wall or pillar
Ø4.0 mm
129 mm
694 mm
139 mm
53 mm
Wall mounting holeWall mounting hole
26 mm
htb600.400_TQBJ2216_en.fm Page 15 Thursday, May 14, 2020 2:22 PM

Panasonic SC-HTB600 Specifications

General

Audio decoders	DTS 96/24, DTS Digital Surround, DTS Virtual:X, DTS-ES, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Surround, Dolby TrueHD
RMS rated power	360 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Product color	Black
TV stand usage	-
Soundbar speaker RMS power	160 W
Subwoofer connectivity	Wireless
Wi-Fi	No
HDMI in	1
Bluetooth version	5.0
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Soundbar power consumption	30 W
Power consumption (standby)	2 W
Subwoofer power consumption	36 W
Cables included	AC
Harmonized System (HS) code	85182200

Weight and Dimensions

Depth	120 mm
Width	962 mm
Height	56 mm
Soundbar weight	3300 g
Subwoofer depth	385 mm
Subwoofer width	191 mm
Subwoofer height	413 mm
Subwoofer weight	8400 g
