“TEMP NG”
• The temperature protection circuit has been activated, and
the system will switch off. Let the unit cool down before
switching it on again.
• Check that the ventilation opening of the unit is not
obstructed.
• Ensure this unit is well ventilated.
“TRK FULL”
• The number of files has exceeded the supported limit.
“USB A NO DEVICE”
“USB B NO DEVICE”
• The USB device is not connected. Examine the connection.
“USB OVER CURRENT ERROR”
• The USB device is using too much power. Disconnect the
USB device, switch off the system and then switch on
again.
“VBR”
• The system cannot show the remaining play time for
variable bit rate (VBR) tracks.
Remote control code
When other Panasonic equipment responds to the
remote control of this system, change the remote control
code for this system.
Preparation
Press [CD/RADIO/AUX] to select
SC-MAX9000 SC-MAX7000 : “AUX 1”, “AUX 2”, “AUX 3” or
“AUX 4”.
SC-MAX5000 : “AUX 1” or “AUX 2”.
█ To set the code to “REMOTE 2”
1 Press and hold [CD/RADIO/AUX] on the main unit
and [2] on the remote control until “REMOTE 2” is
shown.
2 Press and hold [OK] and [2] for a minimum of
4 seconds.
█ To set the code to “REMOTE 1”
1 Press and hold [CD/RADIO/AUX] on the main unit
and [1] on the remote control until “REMOTE 1” is
shown.
2 Press and hold [OK] and [1] for a minimum of
4 seconds.
System memory reset
Reset the memory when the following situations occur:
• There is no response when buttons are pressed.
• You want to clear and reset the memory contents.
1 Disconnect the AC mains lead.
2 While you press and hold [1] on the main unit,
connect the AC mains lead again.
Continue to press and hold the button until
“–––––––––” is shown.
3 Release [1].
All the settings are set back to the factory preset.
It is necessary to set the memory items again.
Specifications
█ Amplifier section
RMS output power stereo mode
SC-MAX9000
High Ch 500 W per channel (3 Ω), 1 kHz, 30% THD
Mid Ch 500 W per channel (3 Ω), 1 kHz, 30% THD
Low Ch 1000 W per channel (5 Ω), 100 Hz, 30% THD
Total RMS stereo mode power 4000 W
SC-MAX7000
Front Ch 350 W per channel (3 Ω), 1 kHz, 30% THD
Front Ch 350 W per channel (3 Ω), 1 kHz, 30% THD
Subwoofer Ch 800 W per channel (6 Ω), 100 Hz,
30% THD
Total RMS stereo mode power 3000 W
SC-MAX5000
High Ch 350 W per channel (3 Ω), 1 kHz, 30% THD
Mid Ch 350 W per channel (3 Ω), 1 kHz, 30% THD
Low Ch 500 W per channel (2 Ω), 100 Hz, 30% THD
Total RMS stereo mode power 2400 W
█ Tuner section
Frequency modulation (FM)
Preset memory 30 stations
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75 Ω (unbalanced)
Amplitude modulation (AM)
Preset memory 15 stations
Frequency range 522 kHz to 1629 kHz (9 kHz step)
520 kHz to 1630 kHz (10 kHz step)
█ Disc section
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3 )
MPEG-1 Layer 3, MPEG-2 Layer 3
Pick up
Wavelength 790 nm (CD)
█ Bluetooth
®
section
Version Bluetooth
®
Ver. 2.1 + EDR
Class Class 2
Supported profiles A2DP, AVRCP, SPP, OPP, FTP
Operating frequency 2.4 GHz band FH-SS
Operation distance 10 m line of sight
