Specifications
█ Amplifier section
SC-MAX8700
RMS output power stereo mode
High Ch 500 W per channel (3 Ω), 1 kHz, 30% THD
Mid Ch 500 W per channel (3 Ω), 1 kHz, 30% THD
Low Ch 1000 W per channel (5 Ω), 100 Hz, 30% THD
Total RMS stereo mode power 4000 W
FTC output power stereo mode
High Ch (both ch driven) 180 W per channel (3 Ω),
100 Hz to 20 kHz, 1% THD
Mid Ch (both ch driven) 180 W per channel (3 Ω),
100 Hz to 20 kHz, 1% THD
Low Ch 300 W per channel (5 Ω), 60 Hz to 200 Hz,
1% THD
Total FTC stereo mode power 1320 W
SC-MAX4700
RMS output power stereo mode
High 350 W per channel (3 Ω), 1 kHz, 30% THD
Mid 350 W per channel (3 Ω), 1 kHz, 30% THD
Low 500 W per channel (2 Ω), 100 Hz, 30% THD
Total RMS stereo mode power 2400 W
FTC output power stereo mode
High 80 W per channel (3 Ω), 2 kHz to 20 kHz,
1% THD
Mid 80 W per channel (3 Ω), 80 Hz to 4 kHz,
1% THD
Low 100 W per channel (2 Ω), 50 Hz to 170 Hz,
1% THD
Total FTC stereo mode power 520 W
█ Terminal section
USB port
USB standard USB 2.0 full speed
Media file format support MP3 (*.mp3)
USB device file system FAT12, FAT16, FAT32
AUX IN 1
Audio input Pin jack
AUX IN 2
Terminal Stereo, 3.5 mm (
1
/
8
") jack
Microphone
Terminal Mono, 6.3 mm (
1
/
4
") jack
█ Tuner section
Frequency modulation (FM)
Preset memory 30 stations
Frequency range
87.9 MHz to 107.9 MHz (200 kHz step)
87.5 MHz to 108.0 MHz (100 kHz step)
Antenna terminals 75 Ω (unbalanced)
Amplitude modulation (AM)
Preset memory 15 stations
Frequency range 520 kHz to 1710 kHz (10 kHz step)
█ Disc section
Disc played [8 cm (3") or 12 cm (5")]
CD, CD-R/RW (CD-DA, MP3 )
MPEG-1 Layer 3, MPEG-2 Layer 3
Pick up
Wavelength 790 nm (CD)
█ Bluetooth
®
section
Version Bluetooth
®
Ver. 2.1 + EDR
Class Class 2
Supported profiles A2DP, AVRCP, SPP, OPP
Operating frequency 2.4 GHz band FH-SS
Operation distance 10 m (33 ft) line of sight
█ Speaker section
SB-MAX8700
Speaker unit(s)
Tweeter 6 cm (2
3
/
8
") cone type x 1
Woofer 16 cm (6
1
/
2
") cone type x 2
Super Woofer 38 cm (15") cone type x 1
Impedance High 3 Ω / Mid 3 Ω / Low 5 Ω
Dimensions (W x H x D)
Including speaker feet 572 mm x 782 mm x 528 mm
(22
1
/
2
" x 30
3
/
4
" x 20
3
/
4
")
Excluding speaker feet 572 mm x 774 mm x 528 mm
(22
1
/
2
" x 30
1
/
2
" x 20
3
/
4
")
Mass 37 kg (81.6 lbs)
SB-MAX4700
Speaker unit(s)
Tweeter 6 cm (2
3
/
8
") cone type
Woofer 20 cm (7
7
/
8
") cone type
Super Woofer 30 cm (12") cone type
Impedance High 3 Ω / Mid 3 Ω / Low 2 Ω
Dimensions (W x H x D) 407 mm x 709 mm x 389 mm
(16" x 27
7
/
8
" x 15
3
/
8
")
Mass 19 kg (41.9 lbs)
█ General
Power supply AC 120 V, 60 Hz
Power consumption
SC-MAX8700 340 W
SC-MAX4700 240 W
Dimensions (W x H x D) 460 mm x 234 mm x 409 mm
(18
1
/
8
" x 9
1
/
4
" x 16
1
/
8
")
Mass
SC-MAX8700 6.0 kg (13.2 lbs)
SC-MAX4700 5.5 kg (12.1 lbs)
Operating temperature range
0°C to +40°C (+32°F to +104°F)
Operating humidity range
35% to 80% RH (no condensation)
Note:
• Specifications are subject to change without notice.
Mass and dimensions are approximate.
• Total harmonic distortion is measured by the digital
spectrum analyzer.
Power consumption in standby mode (approximate)
0.4 W
Power consumption in standby mode (approximate)
(With “BLUETOOTH STANDBY” set to “ON”)
0.5 W
