RQTV0216
5
ENGLISH
To household
mains socket
4
Connect the AC mains lead.
READ THE CAUTION FOR THE AC MAINS LEAD ON PAGE 3
BEFORE CONNECTION.
The included AC mains lead is for use with this unit only. Do not
use it with other equipment.
Insertion of connector
Even when the connector is perfectly inserted, depending on
the type of inlet used, the front part of the connector may jut out
as shown in the drawing. However there is no problem using
the unit.
2
Connect the speaker cables.
Incorrect connection can damage the unit.
Copper (ª)
Silver (·)
Red (ª)
Black (·)
Red (ª)
Black (·)
Connector
Appliance inlet
