Matsushita Electric Industrial Co., Ltd.
Web Site: http://panasonic.net
Pursuant to at the directive 2004/108/EC, article 9(2)
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
RQTV0273-4B
L0208SN4068
En
AMPLIFIER SECTION
RMS Output Power Stereo Mode
Front Ch (both ch driven)
80 W per channel (3 Ω), 1 kHz, 10% THD
Total RMS Stereo mode power 160 W
FM TUNER, TERMINALS SECTION
Frequency Modulation (FM)
Preset memory FM 30 stations
Frequency range 87.50 to 108.00 MHz (50 kHz step)
Sensitivity 4.5 dBµV (IHF)
S/N 50 dB 9.0 dBµV
Antenna terminals 75 Ω (unbalanced)
Music Port input jack
Sensitivity 100 mV, 11 kΩ
Terminal Stereo, 3.5 mm jack
Phone jack
Terminal Stereo, 3.5 mm jack
OPTION port Version 1
DAB External Antenna
Terminal F-Connector (75 Ω)
CD SECTION
Disc played (8cm or 12 cm)
(1) CD, CD-R/RW (CD-DA, MP3
*
)
*
MPEG-1 Layer 3, MPEG-2 Layer 3
Pick up
Wavelength (CD) 785 nm
Laser power (CD) CLASS 1
(For Norge)
Bølgelengde 785 nm
Laserstyrke Ingen farlig stråling sendes ut
Audio output (Disc)
Number of channels (FL, FR), 2 Channel
USB SECTION
USB port
USB standard USB 2.0 full speed
Media fi le format support MP3 (*.mp3)
USB device fi le system FAT 12 / FAT 16 / FAT 32
USB port power Max 500 mA
USB ripping bit rate 128 / 192 / 320 kbps
Frequency response 4 Hz to 20 kHz
Output level ( 1 kHz, 0 dB) 1000 mV ± 150 mV
S/N ratio > 80 dB
Dynamic range > 80 dB
Separation > 60 dB
Total harmonic distortion < 0.1 %
USB recording speed 1x, 4x (CD only)
Recording fi le format MP3 (*.mp3)
DAB SECTION
Frequency Band (wavelength)
Band III (UK Only) 11B to 12D (218.640 MHz to 229.072 MHz)
Band III (Europe) 5A to 13F (174.928 MHz to 239.200 MHz)
L Band LA to LW (1452.960 MHz to 1490.624 MHz)
Intermediate frequency 1st : 38.912 MHz, 2nd : 2.048 MHz
Sensitivity *BER 4x10
-4
MAX. input power 0 dBm
Min requirement -98 dBm
Selectivity
Adjacent channel (Band III) 33 dB
Far-Off channel (Band III) 45 dB
DAB memories 20 channels
SPEAKER SECTION
Type 3 way, 3 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3 Ω
1. Tweeter 1.9 cm soft dome type
2. Woofer 14 cm cone type
3. Super tweeter 1.5 cm piezo type
Input power (IEC) 80 W (Max)
Output sound pressure 81 dB/W (1.0 m)
Cross over frequency 5.3 kHz, 10 kHz
Frequency range 41 Hz to 65 kHz (-16 dB)
48 Hz to 58 kHz (-10 dB)
Dimensions (W x H x D) 161 mm x 240 mm x 262 mm
Mass 2.6 kg
GENERAL
Power supply AC 230 to 240 V, 50 Hz
Power consumption 85 W
Dimensions (W x H x D) 175 mm x 240 mm x 349.8 mm
Mass 4.5 kg
Operating temperature range 0˚C to +40˚C
Operating humidity range 35 % to 80 % RH (no condensation)
Power consumption in standby mode 0.7 W (approximate)
Note
1. Specifi cations are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
