Specifications
39
RQTX0105
[PT960] [Front\speakers\SB-HF960]
Type 2 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 6 ≠
1. Full range 6.5 cm (2
1
/2z) Cone type
2. Full range 6.5 cm (2
1
/2z) Cone type
Input power (IEC) 250 W
§6
(Max)
Output sound pressure 83 dB/W (1.0 m)
Cross over frequency 5 kHz
Frequency range 79 Hz to 25 kHz (j16 dB)
95 Hz to 22 kHz (j10 dB)
Dimensions (WtHtD) 252 mmk1123 mmk235 mm
(9
29
/32zk44
7
/32zk9
1
/4z)
Mass [Weight] 3.7 kg (8.2 lbs)
[PT960] [PT954] [Surround\speakers\SB-HS960]
Type 1 way, 1 speaker system (Bass reflex)
Speaker unit(s) Impedance 3 ≠
Full range 6.5 cm (2
1
/2z) Cone type
Input power (IEC) 125 W
§6
(Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 86 Hz to 25 kHz (j16 dB)
98 Hz to 22 kHz (j10 dB)
Dimensions (WtHtD) 252 mmk1123 mmk235 mm
(9
29
/32zk44
7
/32zk9
1
/4z)
Mass [Weight] 2.4 kg (5.2 lbs)
[Center\speaker\SB-HC760]
Type 2 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 6 ≠
1. Full range 6.5 cm (2
1
/2z) Cone type
2. Full range 6.5 cm (2
1
/2z) Cone type
Input power (IEC) 250 W
§6
(Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 5 kHz
Frequency range 80 Hz to 25 kHz (j16 dB)
96 Hz to 22 kHz (j10 dB)
Dimensions (WtHtD) 270 mmk94 mmk95 mm
(10
5
/8zk3
11
/16zk3
3
/4z)
Mass [Weight] 1.3 kg (2.9 lbs)
[Subwoofer\SB-HW560]
Type 1 way, 1 speaker system (Kelton type)
Speaker unit(s) Impedance 6 ≠
1. Woofer 16 cm (6
1
/2z) Cone type
2. Passive Radiator 25 cm (10z)
Input power (IEC) 250 W (Max)
Output sound pressure 78 dB/W (1.0 m)
Frequency range 35 Hz to 200 Hz (j16 dB)
40 Hz to 198 Hz (j10 dB)
Dimensions (WtHtD) 181 mmk361 mmk315 mm
(7
1
/8zk14
7
/32zk12
13
/32z)
Mass [Weight] 4.7 kg (10.4 lbs)
Power supply
[U.S.A.]and]Canada] AC 120 V, 60 Hz
[Others] AC 110 V to 127 V/220 V to 240 V, 50/60 Hz
Power consumption [PT760] [PT954] Main unit 130 W
[PT960] Main unit 135 W
Dimensions (WtHtD) 430 mmk68 mmk327 mm
(1
6
15
/
16
zk
2
11
/
16
zk
12
7
/
8
z
)
Mass [Weight] Main unit 3.7 kg (8.2 Ibs)
Operating temperature range 0 oC to r40 oC (r32 oF to r104 oF)
Operating humidity range 35 % to 80 % RH (no condensation)
[AMPLIFIER\SECTION]
RMS output power
Surround Ch 125 W per channel (3 ≠), 1 kHz, 10 % THD
Total RMS power 250 W
FTC output power
Surround Ch 34 W per channel (3 ≠), 120 Hz to 20 kHz, 1 % THD
Total FTC power 68 W
[RF\SECTION]
Wireless module
Frequency range 2.400 GHz to 2.4835 GHz
No. of channels 3
[GENERAL]
Power supply
[U.S.A.]and]Canada] AC 120 V, 60 Hz
[Others] AC 110 V to 240 V, 50/60 Hz
Power consumption Digital transmitter 1.5 W
Wireless system [U.S.A.]and]Canada] 35 W
[Others] 43 W
Dimensions (WtHtD) Digital transmitter
65 mm
k
52 mm
k
8.6 mm
(2
9
/
16
zk
2
1
/
16
zk
11
/
32
z
)
Wireless system
165 mm
k
90 mm
k
164 mm
(6
1
/
2
zk
3
17
/
32
zk
6
15
/
32
z
)
Mass [Weight] Digital transmitter 0.02 kg (0.04 Ibs)
Wireless system 0.655 kg (1.54 Ibs)
§6
Rating with low-cut filter equipped amplifier
[Note]
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by a digital spectrum analyzer.
GENERAL
Power consumption in standby mode
[U.S.A.]and]Canada] approx. 0.3 W
[Others] approx. 0.4 W
WIRELESS SYSTEM AND DIGITAL TRANSMITTER
Power consumption in off mode
[U.S.A.]and]Canada] approx. 0.2 W
[Others] approx. 0.3 W
SC-PT760-960P-PC_Body5_Eng.fm Page 39 Friday, February 29, 2008 5:09 PM
