13
TQBJ2251
LED indicators
The indicators show the condition of this system. The indicator patterns illustrated below are shown during normal
operational conditions. They do not refer to the indications of a problem.
Indicators Description
D.BASS CHARGE USB AUX
The indicator blinks 5 times.
• When the auto power down setting is off (
~10).
The indicator blinks 2 times.
• When maximum or minimum volume is reached.
• When the auto power down setting is on (
~10).
D.BASS CHARGE USB AUX
The indicator lights up.
• Charging device (
~9).
The indicator blinks.
• Error detected (
~11).
D.BASS CHARGE USB AUX
The indicator blinks.
• You are connecting a USB device and the system is reading the files
(
~7).
The indicator blinks slowly.
• The USB device is not connected.
• The format of the USB device or the contents in it are not compatible with
the system. (
~7).
The indicator blinks quickly.
• The USB device is drawing too much power. Disconnect the USB device.
• Check the connection, it may be caused by a faulty USB cable.
The indicator lights up.
• The USB device is connected (
~7).
D.BASS CHARGE USB AUX
The indicator blinks 2 times.
• When input level is set to high (
~10).
The indicator blinks 5 times.
• When input level is set to normal (
~10).
D.BASS CHARGE USB AUX
The indicator blinks quickly.
• When the unit is ready for pairing (
~7).
The indicator blinks slowly.
• When the unit is waiting to connect (
~7).
The indicator lights up.
• When the unit is connected to a Bluetooth
®
device (~7).
D.BASS CHARGE USB AUX
The indicators blink until the system restarts.
• When the unit is reset (
~12).
D.BASS CHARGE USB AUX
or
D.BASS CHARGE USB AUX
or
D.BASS CHARGE USB AUX
The indicators blink before the system is switched off (at one second
intervals).
• When the auto power down setting is set to on. (
~10).
TMAX5EB.GN_TQBJ2251 En.fm Page 13 Thursday, June 4, 2020 2:11 PM
