Specifications
█
General
Power supply AC 220 V to 240 V, 50 Hz
Power consumption 50 W
Power consumption in standby mode (approximate)
With Bluetooth
®
standby set to off 0.4 W
With Bluetooth
®
standby set to on 0.5 W
Dimensions (W x H x D) 250 mm x 475 mm x 265 mm
Mass 7.0 kg
Operating temperature range 0°C to +40°C
Operating humidity range
35% to 80% RH (no condensation)
█
Amplifier section
RMS output power
High Ch (both ch driven)
15 W per channel (8 Ω), 1 kHz, 30% THD
Low Ch (both ch driven)
60 W per channel (4 Ω), 100 Hz, 30% THD
Total RMS power 150 W
█
Terminal section
USB port
USB standard USB 2.0 full speed
Media file format support MP3 (*.mp3)
Audio support format MP3
Sampling frequency 32 kHz, 44.1 kHz, 48 kHz
Audio word size 16 bits
Channel count 2 ch
USB device file system FAT12, FAT16, FAT32
AUX
Sensitivity 100 mV, 4.7 kΩ
Audio input Stereo, 3.5 mm jack
DC IN
Terminal type USB Micro-B, 5 V, 2 A
█
Bluetooth
®
section
Version Bluetooth
®
Ver. 4.2
Class Class 1
Supported profiles A
VRCP, A2DP, SPP
Frequency band 2.4 GHz band FH-SS
Operation distance 10 m line of sight
Supported codec SBC
Operating frequency 2402 MHz to 2480 MHz
Maximum power (EIRP) 10 dBm
█
Speaker section
Speaker unit(s)
Tweeter 5 cm cone type x 2
Woofer 16 cm cone type x 1
█
Wireless charging section
Interface
Conform to Wireless Power Consortium (WPC)
Charging temperature range +10°C to +35°C
Maximum output 10 W
Note:
• Specifications are subject to change without notice.
Mass and dimensions are approximate.
• Total harmonic distortion is measured by the digital
spectrum analyser.
