Panasonic SDR-H85 User Manual

8
VQT2L26 (ENG)
Preparation
Before using
1
Parts identification and
handling
1 LCD monitor
≥ Pull the LCD monitor out in the direction of
the arrow with your fingers.
≥ It can open up to 90o.
≥ It can rotate up to 180o A towards the lens
or 90o B towards the opposite direction.
≥ The brightness and colour level of the
LCD monitor can be adjusted.
2 Intelligent auto/Manual button
[iA/MANUAL] (l 21)
3 Optical image stabilizer button
[ , O.I.S.] (l 25)
4 Power button [ ] (l 17)
5 Delete button [ ] (l 28)
6 Long recording button [LONG REC.]
7 Audio-video output terminal [A/V]
(l 30)
≥ Use the AV cable (only the supplied
cable).
8 USB terminal [ ]
9 Access lamp [ACCESS]
(l 16)
10 SD card slot (l 16)
11 SD card cover [SD CARD] (l 16)
1 23
456789
10
11
Due to limitations in LCD production
technology, there may be some tiny bright
or dark spots on the LCD monitor screen.
However, this is not a malfunction and
does not affect the recorded picture.
SDRS50&T50&H85EP-VQT2L26_mst.book 8 ページ ２００９年１２月２０日 日曜日 午前１１時１分

Panasonic SDR-H85 Specifications

General

Optical zoom	70 x
Image stabilizer	Yes
Focal length range	1.48 - 104 mm
Focal length (35mm film equivalent)	37.4 - 2625 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/8 \
Interface	AV Out
Power consumption (typical)	3.5 W
Display diagonal	2.7 \
Video formats supported	MPEG2
Audio formats supported	AAC
Camera shutter speed	1/25 - 1/8000 s
Minimum illumination	2 lx
USB 2.0 ports quantity	1
Internal storage capacity	80 GB
Product color	Red
Battery type	DC3.6V / 5.0V
Bundled software	VideoCam Suite 3.0

Weight and Dimensions

Depth	107.3 mm
Width	55.1 mm
Height	64 mm
Weight	273 g
