22 Photoshot button [ ] (l 42)
23 When recording: Zoom lever [W/T]
(l 44)
When playing back: Thumbnail
display switch [ / ] (l 60)/
Volume lever [sVOLr] (l 61)
24 Speaker
25 Status indicator (l 21)
26 HDD access lamp [ACCESS HDD]
(SDR-H85) (l 4)
27 DC input terminal [DC IN] (l 14)
≥ Do not use any other AC adaptors
except the supplied one.
28 Grip belt
Adjust the belt length and the pad
position.
1 Flip the belt.
2 Adjust the length.
3 Replace the belt.
29 Battery release lever [BATTERY]
(l 13)
30 Tripod receptacle
27
25
26
2322
28
24
29 30
