Control reference guide
∫ Top of the main unit
∫ Rear of the main unit
[Note]
≥Place the main unit in a horizontal position with the top panel
facing upward.
≥
To allow for proper ventilation and to maintain good airflow around
the main unit, position it with at least 5 cm of space on all sides.
WIRELESS LINK
WIRELESS LINK indicator (B 9)
Unit on/off button
(B 9)
Surround selector
(B 8)
I/D SET
button (B 10)
AC IN (B 8)
Speaker terminals (B 8)
