Panasonic SR-TEJ10 - Circuit Diagram; Wiring Diagram

3
SR-TEJ10, SR-TEJ18
2. CIRCUIT DIAGRAM
3. WIRING DIAGRAM
N
L
Orange
Power
White Micro Switch
NCKeep Warm
Lamp
Rice Cook
Lamp
Red
Side
Heater
Cast
Heater
Thermal
Fuse
Thermal
Fuse
Black Black
No
E Green
Blue
Thermal Fuse Lead Wire A (Black)
Lame Lead Wire A (Black)
Lam Lead Wire C(Red)
Lam Lead Wire B (White)
Side Heater Lead Wire B (Blue)
Rice Cooking Lever
Lamp Lead Wire C (Red)
Side Heater Lead
Wire A (Red)
To Inlet
Body Earth Lead Wire (Green)
Lamp Lead Wire B (White)
Thermal Fuse Lead Wire B (Black)
