Panasonic SR-TMG18

- 12 -
SR-TMG10 / TMG18
4.7 Disassembly cast heater and thermostat case ass’y
1. Loosen a screw for cast heater.
2. Bending leg of thermostat.
3. Lift a thermostat.
Screw
4.8 Disassembly a side heater
1. Pulling out a side heater and after that
if will replace new side heater, keep a
distance between 23 ~ 27 mm.
(see a picture)
23~27
