Panasonic TH-37PA60E

6.12. Remove the SU-Board
1. Remove the screws (×2 ).
2. Remove the flexible cables (SU1, SU2 and SU3) and
remove the bridge connector (SU45).
3. Slide the SU-Board to the left to disconnect from a coupler
(SC41-SU41) on the SC-Board and remove the SU-Board.
6.13. Remove the SD-Board
1. Remove the screws (×2 ).
2. Remove the flexible cables (SD1, SD2 and SD3) and
remove the bridge connector (SD46).
3. Slide the SD-Board to the left to disconnect from a coupler
(SC42-SD42) on the SC-Board and remove the SD-Board.
13
TH-37PA60E / TH-37PD60B / TH-42PA60E / TH-42PD60B
