Panasonic TH-48LZ980Z

13
English
≥ To remove from the TV:
Be sure to remove the pedestal in the following
procedures when you use the wall-hanging bracket or
repack the TV.
1 Remove the cover E.
2 Remove the assembly screws B from the pedestal.
3 Pull out the pedestal from the TV.
1 Remove the cable cover H.
2 Remove the assembly screws G from the pedestal.
3 Pull out the pedestal from the TV.
It is recommended to secure the TV to furniture as shown
to prevent the TV from falling over.
≥ This information is designed to reduce the risk of
injuries caused by the TV falling over. However, no
measure can guarantee protection in all cases.
Attaching the fall-prevention parts
I Screw (1)
J Wood screw (1)
K Band (1)
Removing the pedestal
H
48-inch model
55-inch model
65-inch model
Preventing the TV from falling over
I
K
J
