120

L16403 G0C2R1KA0190 PEAKING COIL 1

L16404 G0C2R1KA0190 PEAKING COIL 1

L16405 G0C2R1KA0190 PEAKING COIL 1

L16406 G0C2R1KA0190 PEAKING COIL 1

L16411 G0C2R1KA0190 PEAKING COIL 1

L16413 G0C2R1KA0190 PEAKING COIL 1

L16414 G0C2R1KA0190 PEAKING COIL 1

L16415 G0C2R1KA0190 PEAKING COIL 1

L16416 G0C2R1KA0190 PEAKING COIL 1

L16472 G0ZZ00002183 PEAKING COIL 1

L16591 G0ZZ00002183 PEAKING COIL 1

L16697 G0C102KA0187 PEAKING COIL 1

L16698 G0C681KA0187 PEAKING COIL 1

L16699 G0C331KA0187 PEAKING COIL 1

L16801 G0ZZ00002183 PEAKING COIL 1

PA5600 K5H5022A0023 FUSE 1

PA9800 K5H4022A0031 FUSE 1

PA9900 K5H5022A0031 FUSE 1

PB30 K1KA05AA0193 5P CONNECTOR 1

PB31 K1KA03AA0192 3P CONNECTOR 1

PB32 K1KA03AA0192 3P CONNECTOR 1

PB36 K1KA03AA0192 3P CONNECTOR 1

PB37 K1KA03AA0192 3P CONNECTOR 1

PC14951 B3PBA0000457 IC 1

PC14952 B3PBA0000457 IC 1

PC14953 B3PBA0000456 IC 1

PC16480 B3PBA0000223 IC 1

PC16601 B3PBA0000223 IC 1

PC16602 B3PBA0000443 IC 1

PC16603 B3PBA0000223 IC 1

PC16705 B3PBA0000456 IC 1

PC16710 B3PBA0000223 IC 1

PC16896 B3PBA0000223 IC 1

PC16897 B3PBA0000223 IC 1

PCB TNPH0721AGS CIRCUIT BOARD A 1 PAVCA

PCB TNPA4243ADS CIRCUIT BOARD PB 1 PAVCA

PCB ETX2MM702MFH CIRCUIT BOARD P 1 PAVCA

PCB TXNC11RLTU CIRCUIT BOARD C1 1 PAVCA

PCB TXNC21RLTU CIRCUIT BOARD C2 1 PAVCA

PCB TNPA4439ALS CIRCUIT BOARD D 1 PAVCA

PCB TXNSC1RLTUS CIRCUIT BOARD SC 1 PAVCA

PCB TXNSD1RLTU CIRCUIT BOARD SD 1 PAVCA

PCB TXNSS1RLTU CIRCUIT BOARD SS 1 PAVCA

PCB TXNSU1RLTU CIRCUIT BOARD SU 1 PAVCA

PCB TNPA4501S CIRCUIT BOARD G 1 PAVCA

PCB TNPA4603ABS CIRCUIT BOARD GH 1 PAVCA

PCB TNPA4139ADS CIRCUIT BOARD GS 1 PAVCA

PCB TNPA4500S CIRCUIT BOARD K 1 PAVCA

PCB TNPA4499S CIRCUIT BOARD S 1 PAVCA

Q2041 2SD0601ARL TRANSISTOR 1

Q2042 2SD0601ARL TRANSISTOR 1

Q2301 2SB0709ARL TRANSISTOR 1

Q2510 2SD0601ARL TRANSISTOR 1

Q2511 2SD0601ARL TRANSISTOR 1

Q3123 2SD0601ARL TRANSISTOR 1

Q3124 2SD0601ARL TRANSISTOR 1

Q3125 2SB0709ARL TRANSISTOR 1

Q3801 2SD0601ARL TRANSISTOR 1

Q3802 2SD0601ARL TRANSISTOR 1

Q3804 2SD0601ARL TRANSISTOR 1

Q4014 2SD0601ARL TRANSISTOR 1

Q4015 2SD0601ARL TRANSISTOR 1

Q4016 B1CFNG000001 FET 1

Q4017 2SD0601ASL TRANSISTOR 1

Q4502 2SD0601ARL TRANSISTOR 1

Q4503 2SD0601ARL TRANSISTOR 1

Q4514 2SB0709ARL TRANSISTOR 1

Safety Ref. No. Part No. Part Name &

Description

Pcs Remarks

Q4515 2SB0709ARL TRANSISTOR 1

Q4516 2SB0709ARL TRANSISTOR 1

Q4517 2SB0709ARL TRANSISTOR 1

Q4522 2SD0601ARL TRANSISTOR 1

Q4523 2SD0601ARL TRANSISTOR 1

Q4528 2SB0709ARL TRANSISTOR 1

Q4529 2SB0709ARL TRANSISTOR 1

Q4530 2SB0709ARL TRANSISTOR 1

Q4531 2SB0709ARL TRANSISTOR 1

Q5522 2SB0709ARL TRANSISTOR 1

Q5600 B1MBEDA00015 FET 1

Q5601 B1MBDDA00003 FET 1

Q5602 B1MBDDA00003 FET 1

Q5603 2SD0601ARL TRANSISTOR 1

Q5604 2SD0601ARL TRANSISTOR 1

Q5684 2SB0709ARL TRANSISTOR 1

Q8300 2SB0709ARL TRANSISTOR 1

Q9010 2SD0601ARL TRANSISTOR 1

Q9058 2SD0601ARL TRANSISTOR 1

Q9059 2SD0601ARL TRANSISTOR 1

Q9060 2SD0601ARL TRANSISTOR 1

Q9061 2SD0601ARL TRANSISTOR 1

Q9805 2SD0601ARL TRANSISTOR 1

Q9806 2SD0601ARL TRANSISTOR 1

Q9807 B1MBDDA00003 FET 1

Q9808 B1MBDDA00015 FET 1

Q9809 B1MBDDA00003 FET 1

Q16002 2PG0060000RP TRANSISTOR 1

Q16003 2PG0060000RP TRANSISTOR 1

Q16004 2PG0060000RP TRANSISTOR 1

Q16021 B1JAEP000002 TRANSISTOR 1

Q16022 B1JAEP000002 TRANSISTOR 1

Q16023 B1JAEP000002 TRANSISTOR 1

Q16024 B1JAEP000002 TRANSISTOR 1

Q16042 B1JAEN000003 TRANSISTOR 1

Q16051 B1JAEN000003 TRANSISTOR 1

Q16102 2SK399800L FET 1

Q16104 2SK399800L FET 1

Q16141 B1HFPFA00001 TRANSISTOR 1

Q16161 B1HFPFA00001 TRANSISTOR 1

Q16171 B1ABRD000003 TRANSISTOR 1

Q16172 B1ADRD000001 TRANSISTOR 1

Q16181 B1ABRD000003 TRANSISTOR 1

Q16182 B1ADRD000001 TRANSISTOR 1

Q16191 B1HFPFA00001 TRANSISTOR 1

Q16251 2SD0601ARL TRANSISTOR 1

Q16280 2SD0601ARL TRANSISTOR 1

Q16301 B1CBGD000001 FET 1

Q16302 B1CFNG000001 FET 1

Q16304 2SB0709ARL TRANSISTOR 1

Q16331 B1CERL000012 FET 1

Q16335 B1CERL000012 FET 1

Q16339 2SK399500L FET 1

Q16401 B1JAEN000002 TRANSISTOR 1

Q16403 B1JAEN000002 TRANSISTOR 1

Q16404 B1JAEN000002 TRANSISTOR 1

Q16421 2PG0060A00RP TRANSISTOR 1

Q16423 2PG0060A00RP TRANSISTOR 1

Q16424 2PG0060A00RP TRANSISTOR 1

Q16442 B1JAEN000003 TRANSISTOR 1

Q16452 B1JAEP000003 TRANSISTOR 1

Q16471 B1ABCF000231 TRANSISTOR 1

Q16501 B1HFPFA00001 TRANSISTOR 1

Q16521 B1HFPFA00001 TRANSISTOR 1

Q16531 B1ABRD000003 TRANSISTOR 1

Q16532 B1ADRD000001 TRANSISTOR 1

Q16551 B1ABRD000003 TRANSISTOR 1

Q16552 B1ADRD000001 TRANSISTOR 1

Q16581 B1ABCF000231 TRANSISTOR 1

Q16601 B1DEET000002 FET 1

Q16602 2SD0601AQL TRANSISTOR 1

Q16603 2SB0709ARL TRANSISTOR 1

Q16604 B1CHPM000001 FET 1

Safety Ref. No. Part No. Part Name &

Description

Pcs Remarks

Main Page

Panasonic TH-C42FD18 - Page 120
