136
C504 ACKZE1H220T ELECTROLYTIC
CAPACITOR
1
C505 ECQV1H224JL P 0.22UF, J, 50V 1
C506 ACKZE1H100T ELECTROLYTIC
CAPACITOR
1
C507 ACKZE1H221T ELECTROLYTIC
CAPACITOR
1
C508 ACKZE1H220T ELECTROLYTIC
CAPACITOR
1
C551 ACKZE1A471C ELECTROLYTIC
CAPACITOR
1
C555 ACKZE1E470T ELECTROLYTIC
CAPACITOR
1
C557 ECQV1473JM2 PLASTIC FILM
CAPACITOR
1
C558 ECQV1H224JL P 0.22UF, J, 50V 1
C559 ECQV1H474JL P 0.47UF, J, 50V 1
C560 ECQV1H224JL P 0.22UF, J, 50V 1
C600 ACDE2R331KP CERAMIC CAPACI-
TOR
1
C601 ECQU2A105MLA PLASTIC FILM
CAPACITOR
1
C602 ECQU2A474MLA P 0.47UF, 250V 1
C603 ECKENA221KBR C 221P 250V 1
C604 ECKENA221KBR C 221P 250V 1
C605 ACDE1R102K7 CERAMIC CAPACI-
TOR
1
C606 AC4MPK105KA3 PLASTIC FILM
CAPACITOR
1
C610 ECQV1H474JL P 0.47UF, J, 50V 1
C611 ACKZE1H220T ELECTROLYTIC
CAPACITOR
1
C612 ACKMQ2W221L ELECTROLYTIC
CAPACITOR
1
C613 ACKMQ2W221L ELECTROLYTIC
CAPACITOR
1
C615 ECKENA221KBR C 221P 250V 1
C625 ACDE1R102K7 CERAMIC CAPACI-
TOR
1
C701 ACKZE1A471C ELECTROLYTIC
CAPACITOR
1
C702 ECQV1H103JL2 P 0.01UF, J, 50V 1
C703 ECQV1H224JL P 0.22UF, J, 50V 1
D251 MA165TAKU DIODE 1
D254 VDD4SBL40 DIODE 1
D351 VDG865C08R DIODE 1
D352 VDAG01AT DIODE 1
D353 VDG865C08R DIODE 1
D401 VDD6SBN20 DIODE 1
D402 VDAG01AT DIODE 1
D403 VDYG901C3R DIODE 1
D501 VDS1WBA80 DIODE 1
D504 VXST3D82BL3 POWER CLAMPER 1
D505 VDAG01AT DIODE 1
D506 VDAG01AT DIODE 1
D551 VDRK39A5 DIODE 1
D556 VDRF101A2S DIODE 1
D601 MA165TAKU DIODE 1
D602 MA165TAKU DIODE 1
D603 VDAP01CT DIODE 1
D604 VDAP01CT DIODE 1
D606 VDS3V60L1 DIODE 1
D702 VDERA83-004T DIODE 1
F201 HU216005BEP CARTRIDGE
FUSE(LEADTYPE)
1
F301 HU216005BEP CARTRIDGE
FUSE(LEADTYPE)
1
F501 HU215002BEP CARTRIDGE
FUSE(LEADTYPE)
1
F601 HU215010BEP CARTRIDGE
FUSE(LEADTYPE)
1
F602 HU215010BEP CARTRIDGE
FUSE(LEADTYPE)
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
IC251 AN1431TBTA INTEGRATED CIR-
CUIT
1
IC352 AN1431TBTA INTEGRATED CIR-
CUIT
1
IC501 MIP3E30MPSCF IC 1
IC555 AN1431TBTA INTEGRATED CIR-
CUIT
1
K601 ALKT329C93 RELAY 1
K602 ALDJ5D2T8 RELAY 1
L401 AYLH8TB681K CHOKE 1
L402 AYH221012HY CHOKE 1
L501 EXCELSA35 BEAD CHOKE 1
L502 EXCELDR35C BEAD CHOKE 1
L503 EXCELDR35C BEAD CHOKE 1
L551 EXCELDR35C BEAD CHOKE 1
L601 AYJ3112308Z FILTER CHOKE 1
L602 AYJ3112308Z FILTER CHOKE 1
L603 ETB50CZ14GAD CHOKE 1
MC201 MDPPNB101 MODULE 1
MC203 MP00R3A1 MODULE 1
MC301 MDPPNB102 MODULE 1
MC352 MDPJFB101 MODULE 1
MC401 MDPPSA102 MODULE 1
MC451 MDPLSB101 MODULE 1
MC501 MDPTZA101 MODULE 1
MC502 MDPHHA101 MODULE 1
MC552 MDPPFC101 MODULE 1
MC601 MDPLPA101 MODULE 1
MC602 MP00P33 MODULE 1
MC603 MP00P30 MODULE 1
MC701 MDPZDA101 MODULE 1
P2 AKB2P3-VH-B CONNECTOR 1
P6 AKB12B-EH-A CONNECTOR 1
P7 AKB11B-EH-A CONNECTOR 1
P9 AKS02B-VT CONNECTOR 1
P11 AKB2P3-VH-B CONNECTOR 1
P12 AKB10B-PH-KS CONNECTOR 1
P25 AKB13B-PH-KS CONNECTOR 1
PC201 VPS2581AL1VH OPTOISOLATOR 1
PC202 VPS2581AL1VH OPTOISOLATOR 1
PC301 VPS2581AL1VH OPTOISOLATOR 1
PC302 VPS2581AL1VH OPTOISOLATOR 1
PC401 VPS2581AL1VH OPTOISOLATOR 1
PC501 VPS2581AL1VH OPTOISOLATOR 1
PC502 VPS2581AL1VH OPTOISOLATOR 1
Q301 VKFMA16N55G FIELD EFFECT
TRANSISTOR
1
Q302 VKFMA16N55G FIELD EFFECT
TRANSISTOR
1
Q351 2SK3704 FIELD EFFECT
TRANSISTOR
1
Q401 2SK3607 FIELD EFFECT
TRANSISTOR
1
Q402 2SA17670Q2TV TRANSISTOR 1
Q403 2SA17670Q2TV TRANSISTOR 1
R202 ERQ14AJ4R7J F 4.7 OHM, J,1/
4W
1
R203 ERDS2FJ334 CARBON FILM
RESISTOR
1
R204 ERDS2FJ334 CARBON FILM
RESISTOR
1
R208 ERG12SJ910J METAL OXIDE FILM
RESISTOR
1
R215 ERG12SJ270J METAL OXIDE FILM
RESISTOR
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
