Panasonic TH-C42FD18 - A-Board Parts Location

87
TH-C42FD18
A-BOARD PARTS LOCATION
TH-C42FD18
A-BOARD PARTS LOCATION
Parts Location
A-BOARD (FOIL SIDE)
Q1101 B-1
Q3123 G-1
Q3124 H-1
Q3125 G-1
Q4016 G-4
Q4505 C-2
Q4529 C-3
Q4530 C-3
Q4531 C-3
Q5684 D-2
Q8300 E-2
TRANSISTOR
IC1101 C-1
IC2008 G-3
IC2106 G-3
IC2107 G-4
IC3001 G-1
IC4500 C-2
IC4501 D-3
IC4512 C-4
IC4513 D-4
IC4514 D-3
IC4515 C-3
IC4516 E-4
IC5400 G-5
IC5401 F-6
IC5600 F-4
IC5601 F-5
IC5606 E-2
IC8004 D-5
IC8300 F-5
IC8502 B-5
IC8503 C-1
IC8505 D-1
ICIC
TP1100 C-1
TP1101 C-1
TP1102 C-1
TP1103 C-1
TP1104 B-2
TP1105 B-2
TP1111 B-2
TP2000 G-3
TP2002 G-4
TP2302 G-4
TP2311 H-4
TP2312 H-4
TP2313 H-4
TP2314 H-5
TP2315 G-4
TP3501 E-3
TP3503 F-5
TP3505 E-4
TP3507 H-3
TP3508 F-6
TP3509 F-6
TP3510 F-6
TP3519 G-5
TP3520 H-5
TP3521 H-6
TP3522 H-6
TP3523 H-6
TP3524 G-6
TP3525 F-6
TP3526 G-6
TP3527 F-6
TP3528 F-6
TP4001 B-2
TP4002 B-2
TP4003 B-2
TP4005 B-2
TP4006 E-2
TP4008 B-2
TP4105 C-5
TP4212 E-6
TP4213 E-6
TP4214 E-6
TP4215 E-6
TEST POINT
Parts Location
A-BOARD (COMPONENT SIDE)
IC1100 H-1
IC2301 C-5
IC3017 G-4
IC4000 C-4
IC4013 F-2
IC4200 E-5
IC4510 G-3
IC4511 E-4
IC4517 H-3
IC4800 F-1
IC8001 G-5
IC8002 E-5
IC8003 F-6
IC
Q1114 H-2
Q2041 G-1
Q2042 F-1
Q2043 G-1
Q2301 C-4
Q4014 G-2
Q4015 G-2
Q4017 F-2
Q4502 H-3
Q4503 F-3
Q4504 F-2
Q4514 F-4
Q4515 F-3
Q4516 F-4
Q4517 F-4
Q4518 H-4
Q4522 F-3
Q4523 G-3
Q4528 F-3
TRANSISTOR
TP1110 H-2
TP3500 F-2
TP3502 B-5
TP3504 H-3
TP3506 D-5
TP3518 C-5
TP4007 C-3
TP8000 G-5
TP8001 G-5
TP8572 G-6
TP8573 G-6
TP8574 G-6
TP
TP4216 E-6
TP4217 E-6
TP4218 E-6
TP4219 E-6
TP4220 E-6
TP4221 E-6
TP4222 E-6
TP4223 E-6
TP4224 E-6
TP4225 E-6
TP4226 E-6
TP4227 E-6
TP4228 E-6
TP4229 E-6
TP4230 E-6
TP4231 E-6
TP4232 E-6
TP4233 E-6
TP4234 E-6
TP4235 E-6
TP4236 F-6
TP4500 C-3
TP4501 D-3
TP4502 C-3
TP4503 C-3
TP4504 C-2
TP4505 D-2
TP4506 B-2
TP4507 D-2
TP4508 C-2
TP4512 D-4
TP4519 D-4
TP4700 H-5
TP4701 H-5
TP5400 H-5
TP5600 F-5
TP5601 F-5
TP5602 F-5
TP8300 G-1
TP8301 E-2
TP8302 E-2
TP8303 E-2
TP8500 D-2
TP8501 D-2
TP8502 C-5
TP8503 C-1
TP8504 F-4
TP8505 H-5
TP8510 E-2
TP8511 E-1
TP8512 E-1
TP8513 E-1
TP8514 E-1
TP8515 E-1
TP8516 E-1
TP8517 E-1
TP8518 E-4
TP8519 E-1
TP8521 C-1
TP8522 C-2
TP8523 C-2
TP8524 D-1
TP8525 C-2
TP8526 C-2
TP8527 C-2
TP8528 C-2
TP8529 C-1
TP8530 C-1
TP8544 C-6
TP8546 B-5
TP8547 C-5
TP8548 C-5
TP8550 D-1
TP8551 C-1
TP8552 C-6
TP8553 C-6
TP8554 C-6
TP8555 C-6
TP8556 C-6
TP8557 D-6
TP8558 C-6
TP8559 C-6
TP8560 C-6
TP8561 C-6
TP8562 C-6
TP8563 C-6
TP8564 B-6
TPSOS F-6
Q5522 D-6
Q5600 C-5
Q5601 C-5
Q5602 C-5
Q5603 C-4
Q5604 D-5
Q8597 E-1
Q8598 E-1
A
