Panasonic TH-L32X10H

TH-L32X10H
30
9 Measurements and Adjustments
9.1. Voltage Chart of A Board
9.2. Voltage Chart of P Board
Power name Test point Specification
SUB1.8V TP5601 1.76 - 1.87
SUB1.2V TP5602 1.18 - 1.29
SUB3.3V TP5600 3.19 - 3.39
SUB5V TP5405 4.9 - 5.1
SUB9V TP5409 8.82 - 9.27
PNL12V TP5413 11.7 - 12.24
MAIN_SND_17V TP5417 16.66 - 17.34
BT30V TP5482 29.4 - 31.2
Power Supply name Measurement Point Normal condition (V) Normal condition (V)
SOUND_VCC TP862 / TP866 15.5 - 18.5V < 3.0
DTV_12V TP865 / TP867 11.4 - 12.6 < 2.0
TUNER5.6V TP853 5.0 - 6.0V 5.0 - 6.0V
5VS TP853 5.0 - 6.0V 5.0 - 6.0V
DC390V TP801 390 - 410V NO CARE
