Panasonic TH-L32X20S

TH-L32X20S
62
12.2. A-Board
A-Board (B Side)
TNPH0849
Parts Location
Ref. No Location Ref. No Location Ref. No Location Ref. No Location
IC1101 I5 IC4802 A8 IC5416 A2 D3300 D4
IC2301 B4 IC4803 D6 IC8001 G7
IC3350 L3 IC4804 D10 IC8402 J6
IC3904 G4 IC5000 K6 IC8921 H9
IC3905 F4 IC5200 B2
IC4800 G10 IC5220 B2
1
A
B
C
D
E
F
G
H
I
K
L
M
J
2 3 4 5 6 7 8 9 10
