English
8
Assembling / Removing the pedestal
24-inch model
Assembly screw (2)
M4 × 12
Pedestal
Assembling the pedestal
A
B
2
1
32-inch model
Assembly screw (3)
M3 × 14
Assembly screw (4)
M4 × 15
Bracket
Base
Preparations
Take out the pedestal and the TV from the packing case
and put the TV onto a work table with the screen panel
down on the clean and soft cloth (blanket, etc.).
Use a flat and firm table bigger than the TV.
Do not hold the screen panel part.
Make sure not to scratch or break the TV.
Assembling the pedestal
1
A
D
C
3
2
B
To Next Page
