Panasonic TX-29PN1D - Page 12

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
DIODE D892 BT149D
DIODE D895 GDZJ5.1B-34
DIODE D896 1N4148WS
DIODE D897 1N4148-34
DIODE D1056 GDZJ3.6A-34
LED D1061 LS5469-GK
DIODE D1132 GDZJ3.9A-34
DIODE D2103 1N4148-34
DIODE D2107 1N4148-34
DIODE D2108 1N4148-34
DIODE D3141 GDZJ8.2C-34
DIODE D3142 GDZJ8.2C-34
DIODE D3143 1N4148-34
DIODE D3144 1N4148-34
PHOTO COUPLER PC841 SFH617A-20P6
TRANSISTORS
TRANSISTOR Q301 BC847B
TRANSISTOR Q302 BC847B
TRANSISTOR Q303 BC847B
TRANSISTOR Q304 BC847B
TRANSISTOR Q305 BC847B
TRANSISTOR Q306 BC847B
TRANSISTOR Q307 BC857B
TRANSISTOR Q308 BC857B
TRANSISTOR Q309 BC857B
TRANSISTOR Q351 2SA1767
TRANSISTOR Q352 2SA1767
TRANSISTOR Q353 2SA1767
TRANSISTOR Q354 BC857B
TRANSISTOR Q501 2SD2195T100
TRANSISTOR Q551 2SC5517000LK
TRANSISTOR Q581 BC857B
TRANSISTOR Q603 BC847B
TRANSISTOR Q605 BC847B
TRANSISTOR Q606 BC847B
TRANSISTOR Q610 BC857B
TRANSISTOR Q611 BC857B
TRANSISTOR Q701 2SK3342TE16Q
TRANSISTOR Q702 MMBT3904
TRANSISTOR Q703 MMBT3904
TRANSISTOR Q841A BC847B
TRANSISTOR Q850 2SC1318-S
TRANSISTOR Q861 BC847B
TRANSISTOR Q880 BC547B/126
TRANSISTOR Q881 BC847B
TRANSISTOR Q882 BC857B
TRANSISTOR Q893 BC847B
TRANSISTOR Q895 BC847B
TRANSISTOR Q1062 BC847B
TRANSISTOR Q2101 BC857B
TRANSISTOR Q2102 BC847B
TRANSISTOR Q2402 BC847B
TRANSISTOR Q2403 BC847B
TRANSFORMERS
TRANSFORMER T553 ETH19Y209AZ
TRANSFORMER T801 ETS35AA6X6AC
COILS
COIL L002 TALV35VB100K
COIL L004 TALV35VB100K
COILL005 EXCELSA35T
COIL L108 ELJFAR68KF2
COILL300 EXCELDR35V
COIL L301 TLTACT4R7K
COIL L553 ELC16B821L
COIL L555 ELC10D821E
COIL L556 ELC08D682E
COIL L601 G0C100JA0055
COIL L602 G0C100JA0055
COIL L603 G0C100JA0055
COIL L604 G0C100JA0055
COILL605 EXCELDR35V
COIL L606 G0C100JA0055
COILL607 EXCELDR25V
COIL L608 G0C100JA0055
COIL L609 G0C100JA0055
COILL610 EXCELSA35T
COIL L611 G0C100JA0055
COIL L613 EXCELSA35V
COIL L614 EXCELSA35V
COILL615 EXCELDR25V
COILL616 EXCELSA35T
COIL L617 EXCELSA35V
COIL L623 EXCELSA35V
COIL L625 EXCELSA35V
COILL820 EXCELSA39V
COILL841 EXCELSA35T
COILL842 EXCELSA35T
COILL844 EXCELSA39V
COILL845 EXCELSA39V
COILL846 EXCELSA35B
COIL L847 TSL0808S470K
COIL L850 G0A471ZA0041
COIL L860 G0A471ZA0041
COIL L861 TLTACT4R7K
COIL L1061 TLT331K991R
COILL2301 EXCELSA35T
COILL2302 EXCELSA35T
COIL L2303 ELJFC100KF
COILL2313 EXCELDR35V
COILL2314 EXCELDR35V
COIL L2321 EXC3BB221H
COIL L2322 EXC3BB221H
COILL2323 EXCELDR35V
COILL2324 EXCELDR35V
COILL2325 EXCELDR35V
COILL2326 EXCELDR35V
COILL2327 EXCELDR35V
COIL L3000 TLTACT2R2K
COIL L3001 TLTACT2R2K
COIL L3002 ELJFC4R7KF
COIL L3003 ELJFC4R7KF
COIL L3004 ELJFC2R2KF
COIL L3005 ELJFC2R2KF
COIL L3006 TLTACT4R7K
COIL L3007 TLTACT4R7K
COIL L3142 SPT0305A6R8K
COIL L3143 SPT0305A6R8K
FILTERS
LINE FILTER LF832 ELF18N012A
FILTER XF101 F4SE-H0E5
CRYSTALS
CRYSTAL X601 4730007267
RESISTORS
S.M.CARBJA4 ERJ6GEY0R00 0.1W - 0 Ω
S.M.CARBJA5 ERJ6GEY0R00 0.1W - 0 Ω
S.M.CARBJA6 ERJ6GEY0R00 0.1W - 0 Ω
S.M.CARBJA8 ERJ6GEY0R00 0.1W - 0 Ω
S.M.CARBJA9 ERJ6GEY0R00 0.1W - 0 Ω
S.M.CARBJA10 ERJ6GEY0R00 0.1W - 0 Ω
S.M.CARBJA11 ERJ6GEY0R00 0.1W - 0 Ω
12
