Panasonic TX-29PN1D - Replacement Parts List

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type
number to your order.
REPLACEMENT PARTS LIST
Important Safety Notice
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
SPEAKER 1 EASG12D552A2
TUNER 2 ENV57K01G3F
REMOTE CONTROL 3 EUR7651010
PANASONIC BADGE 4 TBM0E3002
POWER BUTTON 5 TBX0E81100
5-KEY BUTTON 6 TBX0E81200
CRT FIXING SCREW 7 THT1062J
AV COVER 8 TKP0E12701
CHASSIS RAIL 9 TMZ0E9803
L P.C.B. 10 TNP0EL006AA
FOCUS LEAD ASSY 11 TXJ/FC0DEG1
F.B.T.+ ANODE ASSY 12 ZTFP14501A
MISCELLANEOUS COMPONENTS
BATTERY .R6RC/2P
CRT EARTH SPRING . TES2298
IR WINDOW . TKP0E12601
LED HOLDER . TMW0E704-1
I.C.s
RGB OUTPUT IC351 TDA6108JF
VERTICAL OUTPUT IC451 LA78045-E
MICRO VCT4973FPZF1IC601 GP4L/SW1.03
IC RESET IC603 XC61CN2802TH
POWER SUPPLY IC801 STRW6754LF06
ERROR AMPLIFIER IC840 SE130N
REGULATOR IC850 PQ1CG21H2RZH
REGULATOR IC860 PQ1CG21H2RZH
REGULATOR IC870 C0CBABD00059
AUDIO AMPLIFIER IC2301 LA42072-E
AUDIO SWITCH IC2401 C0JBAS000227
LED RECEIVER RM1062 KSM-602LM2EL
FUSES
FUSE F840 K5D502BNA005
FS LINK F841 TSF19632
DIODES
THERMISTOR CF830 59890T60B110
DIODE D351 1N4148-34
DIODE D352 1N4148-34
DIODE D353 1N4148-34
DIODE D354 1N4148-34
DIODE D357 1N4148-34
DIODE D358 1N4148-34
DIODE D359 1N4148-34
DIODE D360 EU02
DIODE D361 EU02
DIODE D362 EU02
DIODE D402 1SR124-4AT82
DIODE D501 1SR124-4AT82
DIODE D506 1SR124-4AT82
DIODE D507 1N4148-34
DIODE D512 1N4148-34
DIODE D513 1SR124-4AT82
DIODE D515 1SR124-4AT82
DIODE D516 1SR124-4AT82
DIODE D552 1SR124-4AT82
DIODE D556 FMQ-G2FLS699
DIODE D557 RU3LFA1
DIODE D558 1N4148-34
DIODE D561 1N4148-34
DIODE D562 1N4148-34
DIODE D580 MA4130MTA
DIODE D601 DAN217T146
DIODE D604 1N4148WS
DIODE D708 1SR124-4AT82
DIODE D801 EU02
DIODE D802 EU02
DIODE D803 RS406MBSR01
DIODE D810 SARS01LF-F7
DIODE D817 1SR124-4AT82
DIODE D820 MAZ20820A0LS
DIODE D823 1N4148-34
DIODE D824 1N4148-34
DIODE D825 GDZJ6.8C-34
DIODE D840 RU4AMLF-M1
DIODE D841 RU3LFA1
DIODE D842 RU4BLF-L1
DIODE D843 AU02AV0
DIODE D844 1N4148WS
DIODE D845 GDZJ3.3A-34
DIODE D846 1SR124-4AT82
DIODE D847 1N4148-34
DIODE D849 GDZJ3.6A-34
DIODE SFPB-74V D850 B0JCNE000004
DIODE D851 B0HCMM000014
DIODE D852 GDZJ6.8C-34
DIODE D853 MTZJT-777.5B
DIODED854 MA165TA5
DIODE SFPB-74V D860 B0JCNE000004
DIODE D861 B0HCMM000014
DIODE D862 GDZJ20C-34
DIODE D880 GDZJ8.2B-34
DIODE D881 1N4148WS
DIODE D890 MTZJT-7716A
DIODE D891 MTZJT-7716A
