DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CAPC2009 ECJ2VB1H102K 50V 1nF
S.M.CAPC2010 ECJ2VB1H102K 50V 1nF
S.M.CAPC2011 ECJ2VB1H102K 50V 1nF
ELECTC2012 ECA1CM100B 16V 10µF
ELECTC2013 ECA1CM100B 16V 10µF
S.M.CAPC2014 ECJ2VC1H471J 50V 470pF
S.M.CAPC2015 ECJ2VB1H152K 50V 1.5nF
ELECTC2016 ECA1HM100B 50V 10µF
S.M.CAPC2017 ECJ2VB1H102K 50V 1nF
S.M.CAPC2018 ECJ2VB1H102K 50V 1nF
S.M.CAPC2019 ECJ2VB1H102K 50V 1nF
S.M.CAPC2020 ECJ2VB1H102K 50V 1nF
ELECTC2021 ECA1HM3R3B 50V 3.3µF
S.M.CAPC2022 ECJ2FB1H104K 50V 100nF
S.M.CAPC2023 ECJ2VC1H221J 50V 220pF
S.M.CAPC2024 ECJ2VC1H221J 50V 220pF
ELECTC2025 ECA1CM100B 16V 10µF
S.M.CAPC2026 ECJ2FB1H104K 50V 100nF
S.M.CAPC2027 ECJ2VC1H221J 50V 220pF
ELECTC2028 ECA1CM100B 16V 10µF
S.M.CAPC2029 ECJ2VB1H152K 50V 1.5nF
S.M.CAPC2030 ECJ2VC1H471J 50V 470pF
S.M.CAPC2031 ECJ2VC1H070D 50V 7pF
S.M.CAPC2032 ECJ2VC1H470J 50V 47pF
S.M.CAPC2034 ECJ2VC1H010C 50V 1pF
S.M.CAPC2035 ECJ2VC1H010C 50V 1pF
S.M.CAPC2041 ECJ2VF1C334Z 16V 330nF
S.M.CAPC2042 ECJ2VF1C334Z 16V 330nF
S.M.CAPC2043 ECJ2VB1H103K 50V 10nF
ELECT C2044 ECA1CM331B 16V 330µF
ELECTC2046 ECA1CM470B 16V 47µF
ELECTC2047 ECA1CM470B 16V 47µF
S.M.CAPC2048 ECJ2VF1C334Z 16V 330nF
S.M.CAPC2049 ECJ2VF1C334Z 16V 330nF
S.M.CAPC2050 ECJ2VF1C334Z 16V 330nF
S.M.CAPC2051 ECJ2VF1C334Z 16V 330nF
S.M.CAPC2052 ECJ2VC1H221J 50V 220pF
S.M.CAPC2053 ECJ2VC1H221J 50V 220pF
S.M.CAPC2054 ECJ2VC1H221J 50V 220pF
S.M.CAPC2055 ECJ2VC1H221J 50V 220pF
ELECTC2056 ECA1CM470B 16V 47µF
ELECTC2057 ECA1CM470B 16V 47µF
ELECTC2058 ECA1CM470B 16V 47µF
ELECTC2059 ECA1CM470B 16V 47µF
S.M.CAPC2060 ECJ2VF1C334Z 16V 330nF
S.M.CAPC2061 ECJ2VF1C334Z 16V 330nF
S.M.CAPC2062 ECJ2VC1H221J 50V 220pF
S.M.CAPC2063 ECJ2VC1H221J 50V 220pF
ELECTC2361 ECA1VM102B 35V 1000µF
ELECTC2362 ECA1VM102B 35V 1000µF
S.M.CAPC2363 ECJ2VC1H102J 50V 1nF
S.M.CAPC2364 ECJ2VC1H102J 50V 1nF
S.M.CAPC3001 ECJ1VC1H561J 50V 560pF
S.M.CAPC3002 ECJ1VC1H561J 50V 560pF
S.M.CAPC3003 ECJ1VC1H561J 50V 560pF
S.M.CAPC3006 ECJ1VC1H561J 50V 560pF
S.M.CAPC3007 ECJ1VC1H561J 50V 560pF
S.M.CAPC3008 ECJ1VC1H561J 50V 560pF
S.M.CAPC3010 ECJ1VC1H561J 50V 560pF
S.M.CAPC3011 ECJ1VC1H561J 50V 560pF
S.M.CAPC3013 ECJ1VC1H561J 50V 560pF
S.M.CAPC3014 ECJ1VC1H561J 50V 560pF
S.M.CAPC3015 ECJ1VC1H561J 50V 560pF
S.M.CAPC3016 ECJ1VC1H561J 50V 560pF
S.M.CAPC3018 ECJ1VC1H561J 50V 560pF
S.M.CAPC3019 ECJ1VC1H561J 50V 560pF
ELECTC3038 ECA1CM100B 16V 10µF
ELECTC3039 ECA1CM100B 16V 10µF
ELECTC3040 ECA1CM100B 16V 10µF
ELECTC3041 ECA1CM100B 16V 10µF
ELECTC3044 ECA1CM100B 16V 10µF
ELECTC3045 ECA1CM100B 16V 10µF
S.M.CAPC3201 ECJ2VB1H103K 50V 10nF
S.M.CAPC3202 ECJ2VB1H103K 50V 10nF
S.M.CAPC3203 ECJ2VC1H561J 50V 560pF
S.M.CAPC3204 ECJ2VC1H561J 50V 560pF
S.M.CAPC3207 ECJ2VC1H271J 50V 270pF
S.M.CAPC3213 ECJ2VC1H561J 50V 560pF
S.M.CAPC3214 ECJ2VC1H561J 50V 560pF
ELECTC3215 SMG1HV470MT5 50V 47µF
ELECTC3216 SMG1HV470MT5 50V 47µF
S.M.CAPC3217 ECJ2VC1H561J 50V 560pF
S.M.CAPC3218 ECJ2VC1H561J 50V 560pF
TERMINALS AND LINKS
SCART SOCKET JK3001 350536400
SCART SOCKET JK3002 350536400
RCA SOCKET JK3004 YKC21-5861N
AV TERMINAL JK3201 TJB8E026
CRT SOCKET SC381 330550049
SWITCHES
SWITCH SW801 ESB92DA1B
SWITCH SW1003 EVQ21405R
SWITCH SW1004 EVQ21405R
SWITCH SW1005 EVQ21405R
SWITCH SW1006 EVQ21405R
SWITCH SW1007 EVQ21405R
RELAYS
RELAY RL801 8-1419125-3
DIFFERENCES FOR MODEL TX--28PS11D
EXPLODED VIEW
AV PANEL 13 TKP0E11805-1
BACK COVER 14 TKU0E0112
C.R.T. 15 W66EKT50X71
CABINET 16 TKY0E0110-1
D P.C.B. 17 TNP8ED020AN
DEGAUSS COIL 18 TLK8E05197
DOOR LID 19 TKP0E10604
F.B.T. 20 ZTFN65007A
MODEL LABEL 21 TBM0E0245-1
POWER BUTTON 22 TBX0E80401
MISCELLANEOUS COMPONENTS
CARTON . TPC0E42301A
BOTTOM CUSHION . TPD0E0026
TOP CUSHION . TPD0E0027
INSTRUCTION BOOKS
GERMAN . TQB0E0010A2M
ITALIAN . TQB0E0010C3M
FRENCH . TQB0E0010D2M
I.C.s
4MEG EPROM M27W401-80BIC1103 15E0/050/0E
32K EAROM 24C32A10PI27IC1104 1500/1BD
DIODES
DIODE D352 ERA15-04V3
DIODE D353 ERA15-04V3
DIODE D362 ERA15-04V3
DIODE D363 ERA15-04V3
DIODE D372 ERA15-04V3
