DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
EXPLODED VIEW
A P.C.B. 22 A-32LE8P
AC CORD ASSY 23 TXASX01NXA-1
CABINET ASSY 24 TTY0E0270
MODEL LABEL 25 TBM0E1232
PEDESTAL ASSY 26 TTX0E0005-1
POWER BUTTON 27 TBX0E84500
MISCELLANEOUS COMPONENTS
IR/LED PANEL . TKP0E91901
INSTRUCTION BOOKS
GERMAN . TQB0E0562A
DUTCH . TQB0E0562B
ITALIAN . TQB0E0562C
FRENCH . TQB0E0562D
SPANISH . TQB0E0562E
SWEDISH . TQB0E0562F
NORWEGIAN . TQB0E0562G
FINNISH . TQB0E0562H
LITHUANIAN . TQB0E0562I
PORTUGUESE . TQB0E0562J
DANISH . TQB0E0562K
BULGARIAN . TQB0E0562M
ROMANIAN . TQB0E0562N
LATVIAN . TQB0E0562O
POLISH . TQB0E0562P
HUNGARIAN . TQB0E0562Q
CZECH . TQB0E0562R
GREEK . TQB0E0562S
TURKISH . TQB0E0562T
ENGLISH . TQB0E0562U
CROATIAN . TQB0E0562V
SLOVAKIAN . TQB0E0562W
CD ROM . TQB0E0562X
ESTONIAN . TQB0E0562Z
I.C.s
EEPROM IC1120 X24C32LE8P
DIFFERENCES FOR MODEL TX--32LE8PS
EXPLODED VIEW
A P.C.B. 22 A-32LE8P
AC CORD ASSY 23 TXASX01NXA-1
CABINET ASSY 24 TTY0E0373
MODEL LABEL 25 TBM0E1426
PEDESTAL ASSY 26 TTX0E0010-1
POWER BUTTON 27 TBX0E85700
MISCELLANEOUS COMPONENTS
IR/LED PANEL . TKP0E92401
INSTRUCTION BOOKS
GERMAN . TQB0E0651A
DUTCH . TQB0E0651B
ITALIAN . TQB0E0651C
FRENCH . TQB0E0651D
SPANISH . TQB0E0651E
SWEDISH . TQB0E0651F
NORWEGIAN . TQB0E0651G
FINNISH . TQB0E0651H
LITHUANIAN . TQB0E0651I
PORTUGUESE . TQB0E0651J
DANISH . TQB0E0651K
BULGARIAN . TQB0E0651M
ROMANIAN . TQB0E0651N
LATVIAN . TQB0E0651O
POLISH . TQB0E0651P
HUNGARIAN . TQB0E0651Q
CZECH . TQB0E0651R
GREEK . TQB0E0651S
TURKISH . TQB0E0651T
ENGLISH . TQB0E0651U
CROATIAN . TQB0E0651V
SLOVAKIAN . TQB0E0651W
CD ROM . TQB0E0651X
ESTONIAN . TQB0E0651Z
I.C.s
EEPROM IC1120 X24C32LE8P
