Panasonic TX-37LX85F - Setting Inspection

Setting Inspection
Voltage Confirmation
Confirm the following voltages:
P board
Description Test point Position Normal mode Stand by mode Active stand by mode
Panel 12V TP863 P2, pins 16, 17 12,0V +/- 0,35V 0V 12V +/- 0,35V
16V_Audio TP858 P2, pins 20, 21 16V +/- 1V 0V 16V +/- 1V
SUB_9V TP860 P2, pins 11, 12 9V +/- 0,25V 0V 9V +/- 0,25V
STBY_5V6 TP853 P2, pins 1, 2 5,65V +/- 0,25V 5,65V +/- 0,25V 5,65V +/- 0,25V
24V_IN TP856 P2, pins 7, 8 24V +/- 1,5V 0V 24V +/- 1,5V
A board
SUB 1,8V TP5602 1,76V – 1,85V
SUB 1,2V TP5601 1,22V – 1,27V
SUB 3,3V TP5600 3,19V – 3,39V
SUB5V TP1011 4,75V – 5,25V
DVDDIO3,3V/
TVDD3,3V
TP4531 3,23V – 3,37V
BT30V TP2905 29,5V – 31,5V
DVDD1,8V TP4529 1,77V – 1,83V
AUD3,3V TP2031 3,23V – 3,37V
DVDD1,8V TP2032 1,77V – 1,83V
5V TP2030 4,75V – 5,25V
STB 3,3V TP7601 3,23V – 3,37V
MHQLV3,3V TP4235 3,24V – 3,41V
MHQDDRR2,5V TP4210 2,44V – 2,56V
HQ3,3V TP4200 3,18V – 3,47V
MHQVD1,2V TP4201 1,19V – 1,26V
MHQVD3,3V TP4300 3,24V – 3,41V
10
