Self Check
Self-check is used to automatically check the bus lines and hexadecimal code of the TV set. To enter Self-Check mode, keep
pressing the down (-/v) button on the TV set and press the STATUS button on the remote control. To exit Self Check,
switch off the TV set at the power button.
Display Ref. No. Description P.C.B.
ADV IC4510 A/D CONVERTER A-Board
ADAV IC2106 AUDIO PROCESSOR A-Board
TUN TU2901 TUNER A-Board
GENX IC1100 MICROPROCESSOR A-Board
MEM1 IC1101 EEPROM (GENX) A-Board
MEM2 IC8601 EEPROM (PEAKS LITE2) A-Board
AVSW IC3001 AUDIO VIDEO SWITCH A-Board
TEMP IC1000 TEMP SENSOR A-Board
VIF TU2901 TUNER A-Board
HQ1L IC4200 HQ1L A-Board
If the CCU
