Panasonic TX-42A400B - Page 28

Model No. : TX
Model No. : TXModel No. : TX
Model No. : TX-
--
-42A400B
42A400B42A400B
42A400B Parts List
Parts ListParts List
Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
PCB A-42A400B CIRCUIT BOARD A 1 (RTL)PAVCCZ
PCB TXN/K1UTUH CIRCUIT BOARD K 1 (RTL)PAVCCZ
PCB TXN/P1JAVEZ CIRCUIT BOARD P 1 (RTL)PAVCCZ
PCB TXNGK1JAVEZ CIRCUIT BOARD GK 1 (RTL)PAVCCZ
PCB TXNLD1JAVE CIRCUIT BOARD LD 1 (RTL)PAVCCZ
A02 K1KY14BA0484 14P CONNECTOR 1 PAVCCZ
A10 K1KY07BA0483 7P CONNECTOR 1 PAVCCZ
A11 K1MY51BA0526 51P CONNECTOR 1 PAVCCZ
A12 K1KY04BA0387 4P CONNECTOR 1 PAV
CCZ
C1000 F1G1C104A146 C 0.1UF, , 16V 1 PAVCCZ
C1001 F1G1C104A146 C 0.1UF, , 16V 1 PAVCCZ
C1004 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C1005 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C1006 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C1007 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C2008 F1G1E103A172 C 0.01UF, K, 25V 1 PAVCCZ
C2010 F1G1H102A946 C 1000PF, K, 50V 1 PAVCCZ
C2014 F1H1E104A161 C 0.1UF, , 25V 1 PAVCCZ
C2015 F1K1V106A010 C 10UF, , 35V 1 PAVCCZ
C2016 F1G1C104A146 C 0.1UF, , 16V 1 PAVCCZ
C2017 F1G1C103A173 C 0.01UF, K, 16V 1 PAVCCZ
C2023 F1G1H102A946 C 1000PF, K, 50V 1 PAVCCZ
C2024 F1G1H102A946 C 1000PF, K, 50V 1 PAVCCZ
C2025 F1G1H102A946 C 1000PF, K, 50V 1 PAVCCZ
C2026 F1G1H102A946 C 1000PF, K, 50V 1 PAVCCZ
C2027 F1G1H102A946 C 1000PF, K, 50V 1 PAVCCZ
C2028 F1G1H101A948 C 100PF, J, 50V 1 PAVCCZ
C2801 F1H1H103B047 C 10NF, , 50V 1 PAVCCZ
C2802 F1H1H103B047 C 10NF, , 50V 1 PAVCCZ
C2803 F1H1H103B047 C 10NF, , 50V 1 PAVCCZ
C2804 F1H1C104A178 C 0.1UF, -, 16V 1 PAVCCZ
C2806 F1H1H103B047 C 10NF, , 50V 1 PAVCCZ
C2807 F1J1A106A043 C 10UF, , 10V 1 PAVCCZ
C2808 F1H1C104A178 C 0.1UF, -, 16V 1 PAV
CCZ
C2851 F1J1H104A902 C 100NF, , 50V 1 PAVCCZ
C2852 F1J1H104A902 C 100NF, , 50V 1 PAVCCZ
C3004 F1G1H100A963 C 10PF, D, 50V 1 PAVCCZ
C3005 F1G1H100A963 C 10PF, D, 50V 1 PAVCCZ
C3006 F1G1H100A963 C 10PF, D, 50V 1 PAVCCZ
C3008 F1G1C103A173 C 0.01UF, K, 16V 1 PAVCCZ
C3027 F1G1C103A173 C 0.01UF, K, 16V 1 PAVCCZ
C3028 F1G1C103A173 C 0.01UF, K, 16V 1 PAVCCZ
C3029 F1G1C103A173 C 0.01UF, K, 16V 1 PAVCCZ
C3032 F1J1A106A043 C 10UF, , 10V 1 PAVCCZ
C3033 F1J1A106A043 C 10UF, , 10V 1 PAVCCZ
C3045 F1G1H101A948 C 100PF, J, 50V 1 PAVCCZ
C3046 F1G1H101A948 C 100PF, J, 50V 1 PAVCCZ
C3093 F1G1A473A069 C 47NF, , 10V 1 PAVCCZ
C3095 F1G1A473A069 C 47NF, , 10V 1 PAVCCZ
C3097 F1G1A473A069 C 47NF, , 10V 1 PAVCCZ
C3098 F1J1A106A043 C 10UF, , 10V 1 PAVCCZ
C3099 F1G1H470A834 C 47PF, , 50V 1 PAVCCZ
C3100 F1G1H331A830 C 330PF, , 50V 1 PAVCCZ
C3101 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C3102 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C3103 F1G1H101A948 C 100PF, J, 50V 1 PAVCCZ
C3104 F1G1H101A948 C 100PF, J, 50V 1 PAVCCZ
C3105 F1L1C226A068 C 22UF, M, 16V 1 PAVCCZ
C3106 F1L1C226A068 C 22UF, M, 16V 1 PAV
CCZ
28
