47
Receiving Systems PAL B Ch1 to Ch69
PAL 525/60 Playback from Video Tape Recorders.
DVB Digital terrestrial services via aerial input
M.NTSC Playback from M.NTSC Video recorders
NTSC (AV Input only) Playback from NTSC Video recorders
Power Requirements 240Volts +10% 50Hz
Power Consumption 119W Max
Standby Consumption 3.7W (TV only)
17.7W (TV + DVB system set to record Timer programme)
Chassis EURO8D
Tuning System Frequency synthesized.
Picture Tube 76cm Viewable (Measured diagonally)
Audio Output 2 Speaker 20W + 20W
Headphone Socket 3.5mm Stereo 8?
Aerial Impedance 75? Unbalanced coaxial
AV Terminals AV1 (Rear): 21pin Scart Socket Audio/Video In/Out, Y/P
B
/P
R
AV2 (Rear): 21pin Scart Socket Audio/Video In/Out, S-Video,
Q-Link
AV3 (Front): S-Video In, RCA AV In
AV4 (Rear): 21pin Scart Socket Audio/Video In/Out, Y/P
B
/P
R
Monitor Out RCA
Video / Audio S-Video Y: 1.0Vp-p 75? C: 0.3Vp-p 75?
Video in: 1.0Vp-p, 75? Audio in: Approx. 400mV 47k?
Monitor Out Video Out: 1.0Vp-p, 75?? Audio Out: Approx. 400mV
Data connections MODEM 9 pin male D-Type connector – Max. 38.4kbps
SERIAL 9 pin male D-Type connector – Max. 115.2kbps
Accessories Supplied Remote Control EUR511241
2 Batteries Type ‘AA’
Scart to RCA / S-VHS Adaptor CW-30410
Scart to 6 RCA Cable ME-60108
Instruction Manual TQB4A0158P
Dimensions Width = 84.9cm Depth =55.1cm Height = 55.8cm
Weight 57kg (Net)
Note: Design and Specifications are subject to change without notice.
Weight and Dimensions shown are approximate.
