Panasonic TX-L32E30B - Page 39

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CAPC8205 F1J1A106A087 10V 10µF
S.M.CAPC8206 F1G1C104A077 16V 100nF
S.M.CAPC8208 F1G1C104A077 16V 100nF
S.M.CAPC8210 F1G1C104A077 16V 100nF
S.M.CAPC8213 F1G1C104A077 16V 100nF
S.M.CAPC8214 F1J1A106A087 10V 10µF
S.M.CAPC8216 F1G1C104A077 16V 100nF
S.M.CAPC8218 F1G1C104A077 16V 100nF
S.M.CAPC8219 F1G1C104A077 16V 100nF
S.M.CAPC8222 F1G1C104A077 16V 100nF
S.M.CAPC8223 F1G1C104A077 16V 100nF
S.M.CAPC8224 F1G1C104A077 16V 100nF
S.M.CAPC8225 F1G1C104A077 16V 100nF
S.M.CAPC8226 F1G1C104A077 16V 100nF
S.M.CAPC8227 F1G1C104A077 16V 100nF
S.M.CAPC8300 F1G1H9R0A732 50V 9pF
S.M.CAPC8301 F1G1H8R0A732 50V 8pF
S.M.CAPC8302 F1G1C104A077 16V 100nF
S.M.CAPC8303 F1G1C104A077 16V 100nF
S.M.CAPC8304 F1G1C104A077 16V 100nF
S.M.CAPC8305 F1G1A105A047 10V 1000nF
S.M.CAPC8306 F1G1A105A047 10V 1000nF
S.M.CAPC8307 F1G1A105A047 10V 1000nF
S.M.CAPC8308 F1G1A105A047 10V 1000nF
S.M.CAPC8309 F1G1A105A047 10V 1000nF
S.M.CAPC8310 F1G1A105A047 10V 1000nF
S.M.CAPC8311 F1G1A105A047 10V 1000nF
S.M.CAPC8401 F1G1C104A077 16V 100nF
S.M.CAPC8402 F1K0J226A049 6.3V 22µF
S.M.CAPC8403 F1K0J226A049 6.3V 22µF
S.M.CAPC8406 F1G1C104A077 16V 100nF
S.M.CAPC8407 F1G1C104A077 16V 100nF
S.M.CAPC8411 F1G1C104A077 16V 100nF
S.M.CAPC8602 F1G1H390A565 50V 39pF
S.M.CAPC8603 F1J1A106A087 10V 10µF
S.M.CAPC8604 F1G1C104A077 16V 100nF
S.M.CAPC8605 F1G1C104A077 16V 100nF
S.M.CAPC8607 F1G1H100A565 50V 10pF
S.M.CAPC8608 F1G1H100A565 50V 10pF
S.M.CAPC8609 F1G1C104A077 16V 100nF
S.M.CAPC8611 F1G1C104A077 16V 100nF
S.M.CAPC8615 F1J1A106A087 10V 10µF
S.M.CAPC8616 F1J1A106A087 10V 10µF
S.M.CAPC8617 F1G1C104A077 16V 100nF
S.M.CAPC8619 F1G1C104A077 16V 100nF
S.M.CAPC8620 F1G1C104A077 16V 100nF
S.M.CAPC8621 F1G1H100A565 50V 10pF
S.M.CAPC8622 F1G1H100A565 50V 10pF
S.M.CAPC8624 F1G1H100A565 50V 10pF
S.M.CAPC8625 F1G1H100A565 50V 10pF
S.M.CAPC8626 F1G1H100A565 50V 10pF
S.
M
.CAPC8629 F1G1H390A565 50V 39pF
S.M.CAPC8630 F1G1H220A565 50V 22pF
S.M.CAPC8644 F1G1C104A077 16V 100nF
S.M.CAPC8714 F1J1A475A087 10V 4.7µF
S.M.CAPC8715 F1J1A106A087 10V 10µF
S.M.CAPC8716 F1G1C104A077 16V 100nF
S.M.CAPC8717 F1G1C104A077 16V 100nF
S.M.CAPC8724 F1J1A475A087 10V 4.7µF
S.M.CAPC8725 F1J1A475A087 10V 4.7µF
S.M.CAPC8764 F1J1A475A087 10V 4.7µF
S.M.CAPC8765 F1J1A475A087 10V 4.7µF
S.M.CAPC8900 F1G1C104A077 16V 100nF
S.M.CAPC8901 F1G1C104A077 16V 100nF
S.M.CAPC8902 F1G1C104A077 16V 100nF
S.M.CAPC8903 F1G1C104A077 16V 100nF
ELECTC9500 F2A1V4710079 35V 470µF
S.M.CAPC9501 F1K1H225A118 50V 2200nF
S.M.CAPC9502 F1H1C474A143 16V 470nF
S.M.CAPC9503 F1G1E1030005 25V 10nF
S.M.CAPC9505 F1G1E1030005 25V 10nF
S.M.CAPC9506 F1J1A475A087 10V 4.7µF
S.M.CAPC9507 F1H1C474A143 16V 470nF
S.M.CAPC9511 F1J1H182A721 50V 1.8nF
S.M.CAPC9512 F1J1H182A721 50V 1.8nF
S.M.CAPC9513 F1J1H182A721 50V 1.8nF
S.M.CAPC9514 F1J1H182A721 50V 1.8nF
S.M.CAPC9515 F1J1H182A721 50V 1.8nF
S.M.CAPC9516 F1J1H182A721 50V 1.8nF
ELECTC9517 F2A2C5600001 160V 56µF
S.M.CAPC9518 F1G1E1030005 25V 10nF
S.M.CAPC9524 F1L2E1040002 250V 100nF
TERMINALS AND LINKS
15P CONNECTOR A02 K1KY15BA0324
7P CONNECTOR A10 K1KY07AA0719
4P CONNECTOR A12 K1KA04BA0055
51P CONNECTOR A15 K1MY51B00004
14P CONNECTOR CN0100 K1KA14A00248
OPTICAL LINK D1006 K7AAAY000011
YUV,AUDI0 I/O JK1001 K1U710A00002
SCART TERMINAL JK1003 K1FY121A0012
PC TERMINAL JK1005 K1FY315A0009
HDMI TERMINAL JK1020 K1FY119D0015
HDMI TERMINAL JK1021 K1FY119D0015
HDMI TERMINAL JK1022 K1FY119D0015
USB TERMINAL JK1030 K1FY104A0020
USB TERMINAL JK1031 K1FY104A0020
ETHERNET TERMINALJK1040 K2LC1YYA0016
AV IN RCA JK1051 K1U306B00010
HP TERMINAL JK1052 K2HC1YYB0063
HDMI TERMINAL JK1061 K1FY119E0026
CI SLOT JK1070 K1NA68B00056
SD SLOT JK1080 K1NA12E00016
USB TERMINAL JK1090 K1FY104E0009
7P CONNECTOR KA10 K1KA07B00135
12P CONNECTOR LD2 K1KY12BA0322
14P CONNECTOR LD4 K1KY14BA0302
2P CONNECTOR P1 K1KA02B00295
16P CONNECTOR P2 K1KY16BA0311
14P CONNECTOR P4 K1KA14BA0311
PLUG ZA7001 K4AD01A00003
PLUG ZA7003 K4AD01A00003
SWITCHES
SWITCH SW7401 K0F122A00203
SWITCH SW7402 EVQ11G05R
SWITCH SW7403 EVQ11G05R
SWITCH SW7404 EVQ11G05R
SWITCH SW7406 EVQ11G05R
SWITCH SW7407 EVQ11G05R
DIFFERENCES FOR MODEL TX--L32E30B
EXPLODED VIEW
A P.C.B. 18 A-L32E30B
AC CORD 19 K2CT2YY00072
BACK COVER 20 TKU0E8001
CABINET ASSY 21 TXFKY5Z0047
LCD PANEL 22 VVX32F115G00
LD P.C.B. 23 TNPA5377AB
MODEL LABEL 24 TBM0E2499
P P.C.B. 25 TZRNP01PRUE
PACKED STAND ASSY 26 TBL5ZX0140
MISCELLANEOUS COMPONENTS
SIDE AV LABEL . TBM0E2494
RTL
RTL
RTL
X
39
