Panasonic TX-L32E30B - Page 40

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
BOTTOM CUSHION BOTCUS TPD0E2169
CARTON CARTON TPC0EA06601
CLAMPER CK304 TMME268
TOP CUSHION TOPCUS TPD0E1163
INSTRUCTION BOOKS
ENGLISH . TQB0E2096
I.C.s
DDR SDRAMIC8201 C3ABUY000006
NAND FLASH MEMORY IC8900 TVRS077AA
EEPROM STM IC8901 STML32E30B
EEPROM LDA3 IC8902 X24CL32E30B
RESISTORS
SMDJS0033 D0GAR00J0005 .063W 5% 0 Ω
SMDJS0061 D0GAR00J0005 .063W 5% 0 Ω
SMDR9502 D0GDR00J0004 .125W 5% 0 Ω
SMDR9503 D0GDR00J0004 .125W 5% 0 Ω
SMDR9513 D1BA2322A014 .063W 1% 23K2 Ω
SMDR9701 D0GBR00J0004 0.1W 5% 0 Ω
TERMINALS AND LINKS
A02-P2 WIRE A02-P2 TXJA02PQUE
A10-KA10 WIRE A10-KA10 TXJA10PQUE
A12-SPK WIRE A12-SP TXJA12PQUE
LVDS FFC A15-CN5 TSXM422
P4-LD4 WIRE P4-LD4 TXJP04PQUE
DIFFERENCES FOR MODEL TX--L32E30Y
EXPLODED VIEW
A P.C.B. 18 A-L32E30Y
AC CORD 19 K2CQ2YY00085
BACK COVER 20 TKU0E8001
CABINET ASSY 21 TXFKY5Z0047
LCD PANEL 22 VVX32F115G00
LD P.C.B. 23 TNPA5377AB
MODEL LABEL 24 TBM0E2509
P P.C.B. 25 TZRNP01PRUE
PACKED STAND ASSY 26 TBL5ZX0140
MISCELLANEOUS COMPONENTS
SIDE AV LABEL . TBM0E2494
BOTTOM CUSHION BOTCUS TPD0E2169
CARTON CARTON TPC0EA06601
CLAMPER CK304 TMME268
TOP CUSHION TOPCUS TPD0E1163
INSTRUCTION BOOKS
GERMAN . TQB0E2099A
DUTCH . TQB0E2099B
ITALIAN . TQB0E2099C
FRENCH . TQB0E2099D
SPANISH . TQB0E2099E
SWEDISH . TQB0E2099F
NORWEGIAN . TQB0E2099G
FINNISH . TQB0E2099H
LITHUANIAN . TQB0E2099I
PORTUGUESE . TQB0E2099J
DANISH . TQB0E2099K
BULGARIAN . TQB0E2099M
ROMANIAN . TQB0E2099N
LATVIAN . TQB0E2099O
POLISH . TQB0E2099P
HUNGARIAN . TQB0E2099Q
CZECH . TQB0E2099R
GREEK . TQB0E2099S
TURKISH . TQB0E2099T
ENGLISH . TQB0E2099U
CROATIAN . TQB0E2099V
SLOVAKIAN . TQB0E2099W
CD . TQB0E2099X
ESTONIAN . TQB0E2099Z
I.C.s
DDR SDRAM IC8201 C3ABTY000026
NAND FLASH MEMORY IC8900 TVRS076AE
EEPROM STM IC8901 STML32E30Y
EEPROM LDA3 IC8902 X24CL32E30Y
RESISTORS
SMDJS0054 D0GAR00J0005 .063W 5% 0 Ω
SMDJS0055 D0GAR00J0005 .063W 5% 0 Ω
SMDR9502 D0GDR00J0004 .125W 5% 0 Ω
SMDR9503 D0GDR00J0004 .125W 5% 0 Ω
SMDR9513 D1BA2322A014 .063W 1% 23K2 Ω
SMDR9701 D0GBR00J0004 0.1W 5% 0 Ω
TERMINALS AND LINKS
A02-P2 WIRE A02-P2 TXJA02PQUE
A10-KA10 WIRE A10-KA10 TXJA10PQUE
A12-SPK WIRE A12-SP TXJA12PQUE
LVDS FFC A15-CN5 TSXM422
P4-LD4 WIRE P4-LD4 TXJP04PQUE
DIFFERENCES FOR MODEL TX--L37E30B
EXPLODED VIEW
A P.C.B. 18 A-L37E30B
AC CORD 19 K2CT2YY00077
BACK COVER 20 TKU0E7901
CABINET ASSY 21 TXFKY5Z0048
LCD PANEL 22 VVX37F115G00
LD P.C.B. 23 TNPA5377AC
MODEL LABEL 24 TBM0E2500
P P.C.B. 25 TZRNP01PNUE
PACKED STAND ASSY 26 TBL5ZX0144
MISCELLANEOUS COMPONENTS
SIDE AV LABEL . TBM0E2496
BOTTOM CUSHION BOTCUS TPD0E2171
CARTON CARTON TPC0EA06701
HEAT RUBBER_LD FK308 TMKK442
TOP CUSHION CENTERTOPCUS1 TPD0E1166
TOP CUSHION TOPCUS2 TPD0E1165
INSTRUCTION BOOKS
ENGLISH . TQB0E2096
I.C.s
DDR SDRAMIC8201 C3ABUY000006
NAND FLASH MEMORY IC8900 TVRS077AA
EEPROM STM IC8901 STML37E30B
EEPROM LDA3 IC8902 X24CL37E30B
TRANSISTORS
TRANSISTOR Q9500 B1MBCMA00001
RESISTORS
SMDJS0033 D0GAR00J0005 .063W 5% 0 Ω
SMDJS0061 D0GAR00J0005 .063W 5% 0 Ω
SMDR9502 D1BD3R30A066 .125W 1% 3R3 Ω
SMDR9503 D1BD3R30A066 .125W 1% 3R3 Ω
SMDR9513 D1BA1822A014 .063W 1% 18K2 Ω
SMDR9539 D0GAR00J0005 .063W 5% 0 Ω
SMDR9702 D0GBR00J0004 0.1W 5% 0 Ω
CAPACITORS
S.M.CAPC9509 F1J1H182A721 50V 1.8nF
S.M.CAPC9510 F1J1H182A721 50V 1.8nF
TERMINALS AND LINKS
A02-P2 WIRE A02-P2 TXJA02PMUE
A10-KA10 WIRE A10-KA10 TXJA10PMUE
RTL
RTL
RTL
X
RTL
RTL
RTL
X
40
