Panasonic TX-W32D5F - Important Safety Notice; Replacement Parts List

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type
number to your order.
REPLACEMENT PARTS LIST
Im
p
ortant Safet
y
Notice
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
MECHANICAL PARTS
3D WOOFER 1 EABG10P502A2
SPEAKER 2 EASG8P525A2
TUNER 3 ENG29505G
REMOTE CONTROL 4 EUR511220
POWER BUTTON 5 TBX8E057
DOOR LID 6 TKP8E1239
REAR AV PANEL 7 TKP8E1253-3
CHASSIS FRAME 8 TMX8E027
G P.C.B. 9 TNPA0877AB
H P.C.B. 10 TNPA1047AC
POWER CORD 11 TSX8E0027
BATTERY COVER (REMOTE) 12 UR51EC904A
MISCELLANEOUS COMPONENTS
IC SOCKET 832AG11D-ESL
84 PIN IC SOCKET PLCC-84-T
PANASONIC BADGE TBM8E1726
PRESET PANEL TBM8E1860
HOLOGRAM LABEL TBM8E1861
REAR AV LABEL TBM8E1863
LID CATCH TEK6940
SMOKED PANEL TKP8E1240
LED PANEL TKP8E1241
LED HOLDER TMW8E030
P.C.B. BRACKET TMX8E025
BATTERY PACK UM-3DJ-2P
C.R.T. BUSH VP19001
ANODE CABLE ZTBZAD550A
RELAY RL801 TSE1885-1
THERMISTOR R805 232266296706
FIX CLIP SOD9 31221212478
FIX CLIP SOD1 31221212478
INSTRUCTION BOOKS
BULG./ROMANIAN TQB8E2676MN2
POLISH/HUNG. TQB8E2676PQ2
CZECH/ENGLISH TQB8E2676RU2
I.C.s
AUDIO OUTPUT IC251 LA4282
AUDIO AMPLIFIERIC281 TDA2030AV
RGB OUTPUT IC351 TDA6111Q-N4
RGB OUTPUT IC361 TDA6111Q-N4
RGB OUTPUT IC371 TDA6111Q-N4
REGULATOR IC381 TL431ACLPM
VERTICAL OUTPUT IC451 LA7845N
VIDEO PROCESSOR IC601 TDA9330HN1G
POWER SUPPLY IC801 AN8029
ERROR AMPLIFERIC845 SE140N
REGULATOR IC852 TL431ACLPM
LED RECEIVER IC1011 RPM-637CBRL
MICRO PROCESSOR IC1101 SDA5450C47-1
SRAM IC1103 M5M51008BP
EPROM * IC1104 27C2001-K03
RESET IC1105 MN1381-T(TA)
RESET IC1106 MN1381-R(TA)
VPC IC1502 VPC3215CB4TP
CIP IC1503 MB87F1720
DFU IC1504 FJB007S
VP2S IC1505 MB87F2131
3.5V REGULATOR IC1506 AN77L035M-E1
MEMORY IC1507 MB87H2010
CLOCK CONVERTOR IC1509 TLC2932IPWL
CIP IC1510 MB87F1720
PIP PROCESSOR IC1801 SDA9288XEGEG
COLOUR DECODERIC1802 TDA9143-N1
AUDIO PROCESSORIC2101 MSP3410DPPB4
H.P. AMPLIFIER IC2351 AN7108
VIDEO SWITCHIC3001 TEA6415C
9V REGULATOR IC3801 AN7809FLB
8V REGULATOR IC3802 AN7708FLB
8V REGULATOR IC3805 AN7808LB
3.5V REGULATOR IC3806 SI-3033C
FUSES
FUSEF840 XBA2C50TH15
FUSE F845 TR5-T3150
FUSEF846 TR5-T1250
FUSE HOLDERF8401 EYF52BC
FUSE HOLDERF8402 EYF52BC
DIODES
DIODE D001 MA4020
DIODE D002 MA4020
DIODED252 MA165TA5
DIODE D253 MA700TA5
DIODE D254 MA700TA5
DIODED255 MA165TA5
DIODED282 MA165TA5
DIODED284 MA165TA5
DIODED285 MA165TA5
DIODED286 MA165TA5
DIODE D351 ERA15-04V3
DIODE D352 ERA15-04V3
DIODE D361 ERA15-04V3
DIODE D362 ERA15-04V3
DIODE D371 ERA15-04V3
DIODE D372 ERA15-04V3
DIODE D387 MA2160LFS
DIODE D400 MA4104
DIODED401 MA165TA5
13
