Panasonic TX-W32D5F - Waveform Pattern Table

WAVEFORM PATTERN TABLE
NOTE: All waveforms have been taken using a standard colour bar pattern.
6
B - Out
IC601 Pin 42
2.2V
32
µ
s
R - Out
IC601 Pin 40
32
µ
s
2.2V
G - Out
IC601 Pin 41
2.2V
32
µ
s
Vert Drive
IC451 Pin 2
8ms
63V
Vert Out
IC601 Pin 1
8.6ms
0.6V
VFLB
IC451 Pin 5
1V
8.6ms
Video In
IC1101 Pin 68
0.9V
64
µ
s
H - Out
IC601 Pin 8
3.9V
32
µ
s
HFLB
IC601 Pin 13
32
µ
s
7V
32
µ
s
1V
R - Y
IC601 Pin 26
Luminance In
IC601 Pin 28
0.9V
32
µ
s
B - Y
IC601 Pin 27
32
µ
s
1.3V
28
µ
s
6V
H - Out
IC3901 Pin 3
V - Out
IC3901 Pin 21
0.1V
32µs
E/W - Out
IC601 Pin 3
280mV
8.5ms
