SERVICE HINTS
How to remove the rear cover
1. Remove the 10 {9} as shown in Fig.2.
LOCATION OF CONTROLS
3
Screws
Fig.2.
Fig.3.
Focus
Screen
Y - Board
D - BoardE - BoardH - BoardG - BoardF - Board
M - Board
