Panasonic TX-W32D5F - Page 27

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M. CAPC3419 ECUV1H561JCX 50V
560pF
S.M. CAPC3420 ECUV1H561JCX 50V
560pF
S.M. CAPC3421 ECUV1H561JCX 50V
560pF
S.M. CAPC3422 ECUV1H561JCX 50V
560pF
S.M. CAPC3423 ECUV1H561JCX 50V
560pF
S.M. CAPC3424 ECUV1H561JCX 50V
560pF
S.M. CAPC3425 ECUV1H561JCX 50V
560pF
S.M. CAPC3426 ECUV1H561JCX 50V
560pF
S.M. CAPC3427 ECUV1H102JCX 50V
1nF
ELECT C3428 ECEA1HKA4R7 50V
4.7µF
ELECT C3429 ECEA1CKA220 16V
22µF
ELECT C3430 ECEA1HKA4R7 50V
4.7µF
ELECT C3431 ECEA1CN470 16V
47µF
S.M. CAPC3432 ECUV1H104ZFX 50V
100nF
ELECT C3433 ECA1CM221GB 16V
220µF
S.M. CAPC3434 ECUV1H561JCX 50V
560pF
ELECT C3435 ECEA1HKA100 50V
10pF
S.M. CAPC3436 ECUV1H561JCX 50V
560pF
S.M. CAPC3437 ECUV1H561JCX 50V
560pF
ELECT C3438 ECEA1HKA4R7 50V
4.7µF
S.M. CAPC3439 ECUV1H561JCX 50V
560pF
S.M. CAPC3440 ECUV1H561JCX 50V
560pF
ELECT C3441 ECEA1HKA100 50V
10pF
S.M. CAPC3442 ECUV1H561JCX 50V
560pF
S.M. CAPC3443 ECUV1H561JCX 50V
560pF
ELECT C3444 ECEA1HKA4R7 50V
4.7µF
S.M. CAPC3445 ECUV1H102JCX 50V
1nF
ELECT C3446 ECEA1HKA4R7 50V
4.7µF
S.M. CAPC3447 ECUV1H561JCX 50V
560pF
S.M. CAPC3460 ECUV1H561JCX 50V
560pF
S.M. CAPC3461 ECUV1H561JCX 50V
560pF
S.M. CAPC3496 ECUV1H561JCX 50V
560pF
S.M. CAPC3497 ECUV1H561JCX 50V
560pF
S.M. CAPC3498 ECUV1H561JCX 50V
560pF
ELECT C3802 ECA1CM100GB 16V
10µF
ELECT C3803 ECA1EM100GB 25V
0.1µF
S.M. CAPC3804 ECUV1H104ZFX 50V
100nF
S.M. CAPC3805 ECUV1H224ZFX 50V
220nF
ELECT C3806 ECA1HM101GB 50V
100µF
ELECT C3807 ECA1HM100GB 50V
10µF
ELECT C3808 ECA1CM470GB 16V
47µF
ELECT C3814 ECA1HM010GB 50V
1µF
ELECT C3816 ECA1CM471GB 16V
470µF
ELECT C3817 ECA1CM221GB 16V
220µF
S.M. CAPC3818 ECUV1H103KBX 50V
10nF
ELECT C3819 ECA1HM010GB 50V
1µF
ELECT C3821 ECA1HM010GB 50V
1µF
S.M. CAPC3823 ECUV1H104ZFX 50V
100nF
S.M. CAPC3824 ECUV1H103KBX 50V
10nF
ELECTC3825 ECJ2VB1C224K 350V
220nF
S.M. CAPC3826 ECUV1H103KBX 50V
10nF
TERMINALS AND LINKS
RCA TERMINAL (2P) JK2403 TJB8E014
AV TERMINAL JK3281 TJB8E017
SCART SOCKET JK3401 1364-21-21
SCART SOCKET JK3402 1364-21-21
SCART SOCKET JK3403 1364-21-21
FS LINK R847 TSF19252
FS LINK R848 TSF19402
SWITCHES
SWITCH S840 ESB92S11B
SWITCHS1071 EVQ23405R
SWITCHS1072 EVQ23405R
SWITCHS1073 EVQ23405R
SWITCHS1074 EVQ23405R
SWITCHS1075 EVQ23405R
DIFFERENCES FOR MODEL TX-W28D5F/P
MECHANICAL PARTS
BACK COVER 13 TKU8E00410
C.R.T. 14 W66EHK51X81
C.R.T. FIXING SCREW 15 VP17243
CABINET 16 TKY8E340
CONTROL BRACKET 17 TMW8E032
D P.C.B. 18 TNPA1014AB
DEGAUSS COIL 19 TXFLK01DAG
E P.C.B. 20 TNPH0176AT
F P.C.B. 21 TNPA1068AC
LEFT PANEL 22 TKP8E1245
M P.C.B. 23 TNPA1048AB
MODEL LABEL 24 TQF8E2756
REFLECTOR (L) 25 TKK8E035
REFLECTOR (R) 26 TKK8E034
RIGHT PANEL 27 TKP8E1246
Y P.C.B. 28 TNPA1353AB
MISCELLANEOUS COMPONENTS
TEXTILE TKN8E009
SPEAKER GRILLE TKP8E1247-A
OUTER CARTON TPC8E4702
CUSHION TOP TPD8E669
CUSHION BOTTOM TPD8E670
SPACER CUSHION (R) TPD8E678
SPACER CUSHION (L) TPD8E679
I.C.s
EAROM * IC1102 X24CWH0502NP
DIODES
DIODED561 1SS254T-77
DIODE D565 MTZJT-7736A
DIODED566 MA165TA5
TRANSISTORS
TRANSISTOR Q846 BC547B/126
TRANSISTOR Q847 BC557B/126
TRANSISTOR Q848 BC547B/126
TRANSISTOR Q853 BC557C/126
TRANSISTOR Q854 BC557C/126
TRANSFORMERS
F.B.T. T551 ZTFM05001A
COILS
COIL L363 TLT082K991R
COILL554 EXCELDR35V
FILTERS
LINE FILTER L840 ELF18D850C
LINE FILTER L842 ELF18D850C
RESISTORS
S.M.CARBC3827 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR251 ERJ6GEYJ221 0.1W 5% 220
S.M.CARBR254 ERJ6GEYJ221 0.1W 5% 220
S.M.CARBR257 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR259 ERJ6GEYJ471 0.1W 5% 470
FUSIBLER350 ERQ12AJ151P 0.5W 5% 150
S.M.CARBR356 ERJ6GEYJ181 0.1W 5% 180
SOLIDR358 ERC12GK821C 0.5W 5% 820
S.M.CARBR366 ERJ6GEYJ181 0.1W 5% 180
SOLIDR368 ERC12GK821C 0.5W 5% 820
FUSIBLER370 ERQ1CKPR68 1W 10% R68
S.M.CARBR376 ERJ6GEYJ181 0.1W 5% 180
SOLIDR378 ERC12GK821C 0.5W 5% 820
S.M.CARBR394 ERJ6ENF7500 0.1W 5% 75
27
