Panasonic TX-W32D5F - Page 30

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CARBR3960 ERJ6GEYJ622 0.1W 5% 6K2
S.M.CARBR3961 ERJ6GEYJ272 0.1W 5% 2K7
CARBONR3962 ERD25TJ563 0.25W 5% 56K
S.M.CARBR3963 ERJ6GEYJ563 0.1W 5% 56K
METAL R3972 ERG2FJ471 2W 5% 470
S.M.CARBR3973 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3974 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3975 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3976 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3978 ERJ6GEY0R00 0.1W 5% 0
FUSIBLER3981 ERQ14AJ220 0.25W 5% 22
S.M.CARBR3982 ERJ6GEYJ333 0.1W 5% 33K
S.M.CARBR3983 ERJ6GEYJ823 0.1W 5% 82K
S.M.CARBR3984 ERJ6GEYJ123 0.1W 5% 12K
S.M.CARBR3985 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3986 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR3987 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR3988 ERJ6GEYJ684 0.1W 5% 680K
S.M.CARBR3989 ERJ6GEYJ221 0.1W 5% 220
CAPACITORS
CERAMICC386 ECKC3D392J 2KV
3900pF
CERAMIC C397 ECKC3D222JB 2KV
2200pF
FILMC403 ECQV1H105JZ 50V
1µF
CERAMIC C566 ECKC2H222J 500V
2200pF
FILMC572 ECWH20562JVB 200V
5.6nF
FILMC573 ECQF4103JZH 400V
10nF
FILMC574 ECWF4824JBB 400V
820nF
FILMC575 ECWF4474JBB 400V
470nF
FILMC644 ECQM1H104J 50V
100nF
FILMC645 ECQM1H104J 50V
100nF
FILMC811 ECQM1H104J 50V
100nF
FILMC840 222233510224 50V
220nF
FILMC841 222233510224 50V
220nF
FILMC843 222233510154 50V
100µF
CERAMIC C852 ECKC3D102J 2KV
1nF
ELECT C856 ECA1EM222GB 25V
2200µF
S.M. CAPC906 ECUV1H681KBX 50V
680pF
S.M. CAPC1663 ECUV1H820JCX 50V
82pF
FILMC1901 ECQM1H474J 50V
470nF
FILMC1902 ECQM1H474J 50V
470nF
ELECT C1903 ECA1EM470GB 25V
47µF
S.M. CAPC1904 ECUV1H103ZFX 50V
10nF
S.M. CAPC1905 ECUV1C224KBX 16V
220nF
S.M. CAPC3810 ECUV1H103KBX 50V
10nF
S.M. CAPC3827 ECUV1H224ZFX 50V
220nF
CERAMIC C3830 ECKC1H561J 50V
560pF
FILM C3909 ECQB1H153K 50V
15nF
ELECT C3910 ECA1HM010GB 50V
1µF
FILM C3911 ECQB1H153K 50V
15nF
FILMC3912 ECQM1222JZ 100V
2.2nF
FILMC3913 ECQV1H105JZ 50V
1µF
ELECT C3914 ECA1CM331B 16V
330µF
FILM C3915 ECQB1H103J 50V
10nF
FILM C3916 ECQM1H154J 50V
150nF
FILMC3917 ECQB1H683K 50V
68nF
FILMC3918 ECQB1H222J 50V
2.2nF
FILMC3919 ECQB1H333J 50V
33nF
FILM C3920 ECQB1H332K 50V
3.3nF
CERAMICC3922 ECKC3A182J 1KV
1800pF
ELECT C3923 ECEA1HN100UB 50V
10µF
CERAMIC C3924 ECKC3A122J 1KV
1.2nF
CERAMICC3925 ECKC3A151J 1KV
150pF
CERAMICC3926 ECKC3A681J 1KV
680pF
ELECT C3927 ECA1HM010GB 50V
1µF
FILMC3928 ECQM4223JZW 400V
22nF
FILMC3929 ECQM4223JZW 400V
22nF
CERAMICC3931 ECKC3D101J 2KV
100pF
S.M. CAPC3932 ECUV1H103KBX 50V
10nF
CERAMIC C3933 ECKC3A471J 1KV
470pF
ELECTC3936 ECA2CM330B 160V
33µF
FILMC3937 ECQM1H104J 50V
100nF
ELECT C3939 ECA1HM3R3GB 50V
3.3µF
ELECTC3940 ECA1CMH471B 16V
470µF
ELECTC3941 ECA1HMHR47B 50V
470µF
ELECT C3942 ECEA1HN010UB 50V
1µF
S.M. CAPC3943 ECUV1H101JCX 50V
100pF
FILM C3944 ECQB1H103J 50V
10nF
ELECT C3945 ECA1HM100GB 50V
10µF
FILMC3946 ECQB1H333J 50V
33nF
CERAMIC C3947 ECKC3D102J 2KV
1nF
FILMC3948 ECQV1H105JZ 50V
1µF
FILM C3955 ECQB1H563K 50V
56nF
TERMINALS AND LINKS
FS LINK R1914 TSF19161
30
