English
28
Removing the pedestal
Keep all the removed parts for assembling the
pedestal back to the TV.
Do not lay down the TV with the pedestal on a desk,
etc.
1 Remove the cover
/
1
F
E
2 Remove the assembly screw
2
G
3 Lift up the TV from the pedestal as shown
Tilt the TV backwards
Lift up the TV
3
4 Put the TV onto a work table with the screen panel
down on a clean and soft cloth (blanket, etc.)
To Next Page
