English
29
5 Remove the assembly screw
6 Remove the bracket /
5
6
H
J
I
R
L
R
L
50-inch model
50-inch model
58-inch model
58-inch model
Assembling the pedestal
Be sure to assemble the pedestal in the following way
when you stop using the wall-hanging bracket.
1 Put the TV onto a work table with the screen panel
down on a clean and soft cloth (blanket, etc.)
2 Use the assembly screw
to fasten the bracket /
to the TV securely
3 Raise the TV and tilt the TV backwards, and then
insert the pin
into the pedestal
îî
Do not lay down the TV on a desk, etc. in the
following procedures.
3
K
4 Use the assembly screw to fasten securely
5 Attach the cover
/
To Next Page
