Active Optical Connector V Series
–4–
ACCTB69E 201602-T
DIMENSIONS (Unit: mm)
1. Integrated cable and plug
2. Receptacle
3. Plug and receptacle are mated
External dimensions
General tolerance: ±0.3
L: Cable length
Tolerance
(mm)
Part No.
Unit
50 mm
+10
−0
AYG4V10565
300 mm
+50
−0
AYG4V13065
1m
+100
−0
AYG4V1A065
L12.7
9.1
0.600.40
5.9
(3.9)
External dimensions
Lot No. marking
Note 1
(Suction face)
0.50±0.05
4.50±0.1
8.20
0.50±0.05
3.30
0.10
0.95
0.20±0.03
4.20
5.00
2.80
(1.10) (1.10)
C 0.90
1.72
0.20±0.03
General tolerance: ±0.2
Note 1: The terminal close to the portion to be soldered have nickel barriers (except nickel portions).
Mated height of plug and receptacle
6.5
