Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R6201R 0790207 RESISTOR CHIP
1/16W 1.0K
1
R6203L 0790223 RESISTOR CHIP
1/16W 15K
1
R6203R 0790223 RESISTOR CHIP
1/16W 15K
1
R6204L 0790227 RESISTOR CHIP
1/16W 33K
1
R6204R 0790227 RESISTOR CHIP
1/16W 33K
1
R6205 0790181 RESISTOR CHIP
1/16W 10
1
R6301L 0790207 RESISTOR CHIP
1/16W 1.0K
1
R6301R 0790207 RESISTOR CHIP
1/16W 1.0K
1
R6302L 0790238 RESISTOR CHIP
1/16W 220K
1
R6302R 0790238 RESISTOR CHIP
1/16W 220K
1
R6304 0790216 RESISTOR CHIP
1/16W 4.7K
1
R6308 0790234 RESISTOR CHIP
1/16W 100K
1
R6311 0790229 RESISTOR CHIP
1/16W 47K
1
R6314 0790211 RESISTOR CHIP
1/16W 1.8K
1
R6316 0790242 RESISTOR CHIP
1/16W 390K
1
R6317 0790202 RESISTOR CHIP
1/16W 390
1
R6318 0790202 RESISTOR CHIP
1/16W 390
1
R6319 0790211 RESISTOR CHIP
1/16W 1.8K
1
R6324 0790229 RESISTOR CHIP
1/16W 47K
1
R6325 0790216 RESISTOR CHIP
1/16W 4.7K
1
R6326 0790181 RESISTOR CHIP
1/16W 10
1
R6327 0790209 RESISTOR CHIP
1/16W 1.5K
1
R6328 0790181 RESISTOR CHIP
1/16W 10
1
R6330 0790221 RESISTOR CHIP
1/16W 10K
1
R6333 0790221 RESISTOR CHIP
1/16W 10K
1
R8001 0790207 RESISTOR CHIP
1/16W 1.0K
1 VDR-M95,75
R8002 0790207 RESISTOR CHIP
1/16W 1.0K
1 VDR-M95,75
R8003 0790207 RESISTOR CHIP
1/16W 1.0K
1 VDR-M95,75
R8005 0790073 RESISTOR CHIP
1/16W 470K
1 VDR-M95,75
R8006 0790068 RESISTOR CHIP
1/16W 220K
1 VDR-M95,75
R8042 0790181 RESISTOR CHIP
1/16W 10
1 VDR-M95,75
R8042 0790207 RESISTOR CHIP
1/16W 1.0K
1 VDR-M55,53
R8043 0790181 RESISTOR CHIP
1/16W 10
1 VDR-M95,75
R8043 0790207 RESISTOR CHIP
1/16W 1.0K
1 VDR-M55,53
R8044 0790181 RESISTOR CHIP
1/16W 10
1 VDR-M95,75
R8044 0790207 RESISTOR CHIP
1/16W 1.0K
1 VDR-M55,53
R8045 0790181 RESISTOR CHIP
1/16W 10
1
R8046 0790181 RESISTOR CHIP
1/16W 10
1 VDR-M95,75
R8046 0790207 RESISTOR CHIP
1/16W 1.0K
1 VDR-M55,53
R8047 0790181 RESISTOR CHIP
1/16W 10
1 VDR-M95,75
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R8047 0790207 RESISTOR CHIP
1/16W 1.0K
1 VDR-M55,53
R8048 0790181 RESISTOR CHIP
1/16W 10
1
R8049 0790181 RESISTOR CHIP
1/16W 10
1
R8050 0790181 RESISTOR CHIP
1/16W 10
1
R8051 0790024 RESISTOR CHIP
1/16W 100
1 VDR-M95
R8051 0790194 RESISTOR CHIP
1/16W 100
1 VDR-M75,55,53
R8052 0790194 RESISTOR CHIP
1/16W 100
1
R8053 0790181 RESISTOR CHIP
1/16W 10
1
R8061 0790185 RESISTOR CHIP
1/16W 22
1
R8062 0790185 RESISTOR CHIP
1/16W 22
1
R8063 0790185 RESISTOR CHIP
1/16W 22
1
R8064 0790185 RESISTOR CHIP
1/16W 22
1
R8065 0790185 RESISTOR CHIP
1/16W 22
1
SW8001 FB10741R SWITCH 1
X5001 BL12211R CRYSTAL 1 VDR-M95,75,55
ZD8001 CC02086R DIODE 1 VDR-M95,75
15.2.2. FRT-H/-M/-P C.B.A.
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C1801 AA00968R CAPACITOR CH 6.3V
10U
1
C1803 AA01126R C.CAPACITOR 10V
0.22U
1
C1804 AA01126R C.CAPACITOR 10V
0.22U
1
D1801 CC13061R DIODE 1 VDR-M95
D1801 DAP222 DIODE 1 VDR-M75,55,53
IC1801 CE10291R IC 1
LD1802 CC12281R DIODE 1 VDR-M75,55,53
PD1801 CH12281 DIODE 1
PG1801 EA14631R CONNECTOR 1
PG1802 EA15601R CONNECTOR 1
Q1802 B1ABDF000001 TRANSISTOR 1
Q1803 2SD2345-S TRANSISTOR 1 2SD23450S
R1803 0104084 RESISTOR CHIP
1/16W 2.2M
1
R1805 0790071 RESISTOR CHIP
1/16W 330K
1
R1806 0790046 RESISTOR CHIP
1/16W 4.7K
1
R1807 0790041 RESISTOR CHIP
1/16W 1.8K
1
R1811 AQ10344R RESISTOR CHIP
1/16W 10M
1
R1814 0790019 RESISTOR CHIP
1/16W 47
1
