Panasonic VDR-M95PP - Replacement Parts List

BEFORE REPLACING PARTS, READ THE FOLLOWING:
1. Use only original replacement parts:
To maintain original function and reliability of repaired units,
use only original replacement parts which are listed with
their part numbers in the parts list.
2. IMPORTANT SAFETY NOTICE
Components identified by the sign
have special
characteristics important for safety. When replacing any of
these components, use only the specified parts.
3. Parts whose Ref. Nos. are the same are interchangeable as
replacement parts. Any of these parts may be ordered and
used as a replacement part.
4. Unless otherwise specified;
All resistors are in Ω, K = 1,000 Ω, M = 1,000 kΩ.
5. Abbreviation
RTL: Retention Time Limited
This indicates that the retention time is limited for this item.
After the discontinuation of this item in production, it will no
longer be available.
NR: Non Repairable Board Ass´y
MGF CHIP: Metal Glaze Film Chip
C CHIP: Ceramic Chip
COMPLX CMP: Complex Component
W FLMPRF: Wirewound Flameproof
C.B.A.: Circuit Board Assembly
P.C.B.: Printed Circuit Board
E.S.D.: Electrostatically Sensitive Devices
CSP: Chip Size Package
15.1. Mechanical Replacement Parts
Notes:
Supply of CD-ROM, in accordance with license protection,
is allowable as replacement parts only for customers who
accidentally damaged or lost their own.
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
001 JP43151 AEL C.B.A. 1 (RTL) VDR-
M95,75
001 JP43155 AEL C.B.A. 1 (RTL) VDR-
M55,53
002 JP43231 SHE-H C.B.A. 1 VDR-M95
002 JP43601 SHE-M C.B.A. 1 VDR-M75
003 JP43811 FRT-H C.B.A. 1 (RTL) VDR-M95
003 JP43781 FRT-M C.B.A. 1 (RTL) VDR-M75
003 JP44981 FRT-P C.B.A. 1 (RTL) VDR-
M55,53
004 JP43251 GSL-H C.B.A. 1 VDR-M95
004 JP43621 GSL-M C.B.A. 1 VDR-M75
004 JP44771 GSL-L C.B.A. 1 VDR-M55,53
005 JP43261 DRF-H C.B.A. 1 VDR-M95
005 JP43631 DRF-M C.B.A. 1 VDR-M75
005 JP44991 DRF-P C.B.A. 1 VDR-M55,53
006 JP43801 AVJ-H C.B.A. 1 VDR-M95
006 JP43611 AVJ-M C.B.A. 1 VDR-M75
006 JP45001 AVJ-P C.B.A. 1 VDR-M55
006 JP45002 AVJ-P C.B.A. 1 VDR-M53
007 JP43146 MAN C.B.A. 1 VDR-M95
007 JP43577 MAN C.B.A. 1 VDR-M75
007 JP43587 MAN C.B.A. 1 VDR-M55
007 JP43588 MAN C.B.A. 1 VDR-M53
008 UA12661 DVD DRIVE ASSY 1
101 MC10621 HEAT SINK 1
102 MC10624 HEAT SINK 1
104 MN20271 LCD SHEET 1
106 DP10371 FLASH 1 VDR-M95
107 HP14171 EVF ASSY 1 VDR-M95
107 HP14173 EVF ASSY 1 VDR-M75,55,53
108 QD41462 REAR CASE 1 VDR-M95
108 QD41463 REAR CASE 1 VDR-M75,55
108 QD41465 REAR CASE 1 VDR-M53
113 PC19931 BATTERY BUTTON 1
114 KL15901 BATTERY SPRING 1
115 PV10461 HAND STRAP 1 VDR-M95
115 PV10471 HAND STRAP 1 VDR-M75,55,53
116 EZ10702 BATTERY TERMINAL 1 VDR-M95
117 NA34972 TOP FRAME 1 VDR-M95
117 NA34992 TOP FRAME 1 VDR-M75
117 NA35012 TOP FRAME 1 VDR-M55,53
118 QX17912 TOP CAVER 1 VDR-M95,55,53
118 QX17932 TOP COVER 1 VDR-M75
119 NJ13371 JACK HOLDER 1
120 QD41331 FRONT CASE 1 VDR-M95
120 QD41361 FRONT CASE 1 VDR-M75
120 QD41391 FRONT CASE 1 VDR-M55
120 QD41392 FRONT CASE 1 VDR-M53
121 GH10431 MICROPHONE 1 VDR-M95,55,53
121 GH10432 MICROPHONE 1 VDR-M75
122 QX18221 LENS COVER 1 VDR-M95
122 QX18251 LENS COVER 1 VDR-M75
122 QX18222 LENS COVER 1 VDR-M55,53
123 QX18371 HOOD 1 VDR-M95
123 QX18381 HOOD 1 VDR-M75
123 QX18391 HOOD 1 VDR-M55,53
124 QX17632 EYE CAP 1
126 QX17197 ADJUSTMENT COVER 1
15 Replacement Parts List
139
VDR-M95PP / VDR-M75PP / VDR-M55PP / VDR-M53PP
