Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
129 NA34741 MECHA FRAME 1
130 QD41471 SIDE CASE(R) 1 VDR-M95
130 QD41472 SIDE CASE(R) 1 VDR-M75
130 QD41473 SIDE CASE(R) 1 VDR-M55,53
131 NX27101 LOCK UNIT 1
137 QD40772 COVER(R) 1 VDR-M95
137 QD41612 COVER(R) 1 VDR-M75
137 QD41622 COVER(R) 1 VDR-M55,53
141 MN20341 F CUSHION 1
142 MN20351 R CUSHION 1
148 NX27391 LENS FRAME 1 VDR-M95
148 NX27011 LENS FRAME 1 VDR-M75
148 NX27721 LENS FRAME 1 VDR-M55,53
150 QD41242 SIDE CASE(L) 1
152 NA34692 L PLATE 1
154 QD41152 L COVER 1 VDR-M95
154 QD41212 L COVER 1 VDR-M75
154 QD41154 L COVER 1 VDR-M55,53
155 DB11041 LCD UNIT 1
162 QD41541 FULUCRUM ASSY 1 VDR-M95,75
162 QD41542 FULUCRUM ASSY 1 VDR-M55,53
163 QD41631 LCD CASE(B) 1
165 QD41561 LCD CASE(U) 1 VDR-M95
165 QD41565 LCD CASE(U) 1 VDR-M75
165 QD41563 LCD CASE(U) 1 VDR-M55,53
169 NA35431 J PLATE 1
176 NA34901 LCD FRAME 1
177 MN20291 MONITOR SHEET 1
178 MN19611 DBEF SHEET 1
179 MN19911 BEF2-Y SHEET 1
180 MN19901 BEF2-X SHEET 1
181 KS11101 PLATE 1
182 JP43971 MONITOR C.B.A. 1
183 JP44211 MR C.B.A. 1
184 MN20421 LCD MR SHEET 1
185 MN18088 SPACER SHEET 1
186 MN20561 DIFFUSION SHEET 1
187 MN20541 REFLECTION SHEET 1
B101 MK14206 SCREW 1 VDR-M95
B101 MK14208 SCREW 1 VDR-M75,55,53
B102 MK14202 SCREW 1
B103 MK14206 SCREW 1
B104 MK14206 SCREW 1
B105 MK14206 SCREW 1
B106 MK14206 SCREW 1
B107 MK14206 SCREW 1
B108 MK14202 SCREW 1
B109 MK14202 SCREW 1
B110 MK14206 SCREW 1
B111 MK14206 SCREW 1
B112 MK14206 SCREW 1
B113 MK11911 SCREW 1
B114 MK14206 SCREW 1
B115 MK14206 SCREW 1
B116 MK14206 SCREW 1
B117 MK13791 SCREW 1
B118 MK13791 SCREW 1
B119 MK13791 SCREW 1
B120 MK13791 SCREW 1
B121 MK13791 SCREW 1
B122 MK14206 SCREW 1
B123 MK13782 SCREW 1
B124 MK13782 SCREW 1
B125 MK14206 SCREW 1
B126 MK13782 SCREW 1
B127 MK13782 SCREW 1
B128 MK13782 SCREW 1
B129 MK13782 SCREW 1
B130 MK13782 SCREW 1
B131 MK14202 SCREW 1 VDR-M95,75
B131 MK14208 SCREW 1 VDR-M55,53
B132 MK14202 SCREW 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
B133 MK14206 SCREW 1
B134 MK14202 SCREW 1
B135 MK14202 SCREW 1
B136 MK13782 SCREW 1
B137 MK13782 SCREW 1
B138 MK14206 SCREW 1
B139 MK14206 SCREW 1
B140 MK13782 SCREW 1
B141 MK13782 SCREW 1
B142 MK14291 SCREW 1
B143 MK14291 SCREW 1
B144 MK14291 SCREW 1
B145 MK14208 SCREW 1
B146 MK14208 SCREW 1
B147 MK14208 SCREW 1
B148 MK14208 SCREW 1
B149 MK13782 SCREW 1
B150 7773852 SCREW 1
B151 7773852 SCREW 1
B152 MK14206 SCREW 1
B153 MK14206 SCREW 1
B154 MK14206 SCREW 1
B155 MK13782 SCREW 1
B156 MK13782 SCREW 1
B157 MK13782 SCREW 1
B158 MK11911 SCREW 1
B159 MK11911 SCREW 1
B160 MK13785 SCREW 1
B161 MK13785 SCREW 1
B162 MK13791 SCREW 1 VDR-M75,55,53
B163 MK14202 SCREW 1 VDR-M55,53
B164 MK13791 SCREW 1 VDR-M55,53
601 KQ11341 LENS ASSY 1 VDR-M95
601 KQ11381 LENS ASSY 1 VDR-M75
601 HP14431 LENS ASSY 1 VDR-M55,53
602 UE17151 SENSOR ASSY 1 VDR-M95
602 UE17161 SENSOR ASSY 1 VDR-M75
603 MN20361 SPACER 1 VDR-M95
603 MN20371 SPACER 1 VDR-M75
604 DT10592 CRYSTAL 1 VDR-M95
604 DT10591 CRYSTAL 1 VDR-M75
801 VSK0677 AC ADPTOR 1 TS19155
802 EV11004 AC CABLE 1
803 EW12525 AV CABLE 1
805 EV11011 DC CABLE 1
806 MS10812 SHEET 1
807 VEQ4504 REMOTE CONTROL
UNIT
1 HL11434 VDR-
M95,75,55
808 EW12531 USB CABLE 1 VDR-M95,75,55
809 VQT0R00 OPERATING
INSTRUCTIONS
1 QR35712
811 QX17716 LENS CAP 1 VDR-M95,55,53
811 QX17756 LENS CAP 1 VDR-M75
812 VFF0283 CD-ROM 1 DN11892 VDR-
M95,75,55
See “Notes”.
816 TS16756 SHOLDER STRAP 1 VDR-M95
817 TS16756 SHOLDER STRAP 1 VDR-M75,55,53
851 SP18782 CUSHION 1 VDR-M95,55
851 SP18792 CUSHION 1 VDR-M75
851 SP18921 CUSHION 1 VDR-M53
852 SG28291 PACKING CASE 1 VDR-M95
852 SG28292 PACKING CASE 1 VDR-M75
852 SG28293 PACKING CASE 1 VDR-M55
852 SG28294 PACKING CASE 1 VDR-M53
15.2. Electrical Replacement Parts
Definition of Parts supplier:
1. All parts are supplied from MKE.
140
VDR-M95PP / VDR-M75PP / VDR-M55PP / VDR-M53PP
