Panasonic VDR-M95PP - Page 141

15.2.1. AEL C.B.A.
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
BA7001 FS11091 BATTERY 1 VDR-M95,75,53
BL5001 BM10682R COIL 1 VDR-M95,75,55
BL5002 BM10682R COIL 1 VDR-M95,75,55
BL5004 BM10682R COIL 1 VDR-M95,75,55
BL6001L BM10697R CORE 1
BL6001R BM10697R CORE 1
BL6201 BM10682R COIL 1
BL6202 BM10682R COIL 1
BL8001 BM10349R COIL 1
BL8002 BM10696R COIL 1
BL8003 BM10349R COIL 1
BL8004 BM10696R COIL 1
BL8005 BM10696R COIL 1
BL8006 BM10696R COIL 1
BL8007 BM10349R COIL 1
BL8008 BM10349R COIL 1
BL8009 BM10696R COIL 1
BL8010 BM10345R COIL 1 VDR-M95,75
C3705 AA00968R CAPACITOR CH 6.3V
10U
1
C3706 AA00968R CAPACITOR CH 6.3V
10U
1
C3708 AA00968R CAPACITOR CH 6.3V
10U
1
C3711 AA10872R CAPACITOR CH 10V
0.1U
1
C3713 AA01111R CAPACITOR CH 6.3V
1.0U
1
C3714 AA01111R CAPACITOR CH 6.3V
1.0U
1
C3715 AA01111R CAPACITOR CH 6.3V
1.0U
1
C3717 AD10891R CAPACITOR CH 6.3V
100U
1
C3718 AA01144R C.CAPACITOR 50V
1.0U
1
C5001 AA00968R CAPACITOR CH 6.3V
10U
1 VDR-M95,75,55
C5002 AA00968R CAPACITOR CH 6.3V
10U
1 VDR-M95,75,55
C5003 0893333 C.CAPACITOR CH 16V
0.01U
1 VDR-M95,75,55
C5005 0893333 C.CAPACITOR CH 16V
0.01U
1 VDR-M95,75,55
C5006 AA00966R CAPACITOR CH 6.3V
4.7U
1 VDR-M95,75,55
C5007 0893333 C.CAPACITOR CH 16V
0.01U
1 VDR-M95,75,55
C5008 0893333 C.CAPACITOR CH 16V
0.01U
1 VDR-M95,75,55
C5009 0893265 C.CAPACITOR CH 50V
15P
1 VDR-M95,75,55
C5010 0893265 C.CAPACITOR CH 50V
15P
1 VDR-M95,75,55
C5011 0893333 C.CAPACITOR CH 16V
0.01U
1 VDR-M95,75,55
C5012 0893333 C.CAPACITOR CH 16V
0.01U
1 VDR-M95,75,55
C5013 0893333 C.CAPACITOR CH 16V
0.01U
1 VDR-M95,75,55
C5014 0893333 C.CAPACITOR CH 16V
0.01U
1 VDR-M95,75,55
C6001 0893333 C.CAPACITOR CH 16V
0.01U
1
C6002L 0893324 C.CAPACITOR CH 50V
2200P
1
C6002R 0893324 C.CAPACITOR CH 50V
2200P
1
C6003L AA01111R CAPACITOR CH 6.3V
1.0U
1
C6003R AA01111R CAPACITOR CH 6.3V
1.0U
1
C6004L AD10991R C.CAPACITOR 4V 22U 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C6004R AD10991R C.CAPACITOR 4V 22U 1
C6005L AA01111R CAPACITOR CH 6.3V
1.0U
1
C6005R AA01111R CAPACITOR CH 6.3V
1.0U
1
C6006 AA00968R CAPACITOR CH 6.3V
10U
1
C6021L 0893328 CAPACITOR CH 25V
4700P
1
C6021R 0893328 CAPACITOR CH 25V
4700P
1
C6026 AA01111R CAPACITOR CH 6.3V
1.0U
1
C6027 AA01111R CAPACITOR CH 6.3V
1.0U
1 VDR-M95,75
C6028 AA00968R CAPACITOR CH 6.3V
10U
1
C6029 AA10872R CAPACITOR CH 10V
0.1U
1 VDR-M95,75
C6032 0893268 C.CAPACITOR CH 50V
27P
1
C6101L AA10872R CAPACITOR CH 10V
0.1U
1
C6101R AA10872R CAPACITOR CH 10V
0.1U
1
C6102L 0893354 CAPACITOR CH 16V
0.015U
1
C6102R 0893354 CAPACITOR CH 16V
0.015U
1
C6103L 0893358 CAPACITOR CH 16V
0.033U
1
C6103R 0893358 CAPACITOR CH 16V
0.033U
1
C6104L 0893278 C.CAPACITOR CH 50V
150P
1
C6104R 0893278 C.CAPACITOR CH 50V
150P
1
C6105L AA01143R C.CAPACITOR 16V
0.22U
1
C6105R AA01143R C.CAPACITOR 16V
0.22U
1
C6106 AA00968R CAPACITOR CH 6.3V
10U
1
C6107L 0893331 CAPACITOR CH 25V
6800P
1
C6107R 0893331 CAPACITOR CH 25V
6800P
1
C6108L AA01143R C.CAPACITOR 16V
0.22U
1
C6108R AA01143R C.CAPACITOR 16V
0.22U
1
C6109L 0893333 C.CAPACITOR CH 16V
0.01U
1
C6109R 0893333 C.CAPACITOR CH 16V
0.01U
1
C6111 AA00968R CAPACITOR CH 6.3V
10U
1
C6112 AA00968R CAPACITOR CH 6.3V
10U
1
C6201L AA01143R C.CAPACITOR 16V
0.22U
1
C6201R AA01143R C.CAPACITOR 16V
0.22U
1
C6203L AA01111R CAPACITOR CH 6.3V
1.0U
1
C6203R AA01111R CAPACITOR CH 6.3V
1.0U
1
C6204 AA01113R CAPACITOR CH 6.3V
2.2U
1
C6205 AA00968R CAPACITOR CH 6.3V
10U
1
C6206 AA01111R CAPACITOR CH 6.3V
1.0U
1
C6207 AA01111R CAPACITOR CH 6.3V
1.0U
1
C6301 AA00968R CAPACITOR CH 6.3V
10U
1
C6302 AA00966R CAPACITOR CH 6.3V
4.7U
1
C6303L AA01113R CAPACITOR CH 6.3V
2.2U
1
