Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C6303R AA01113R CAPACITOR CH 6.3V
2.2U
1
C6304L AD10991R C.CAPACITOR 4V 22U 1
C6304R AD10991R C.CAPACITOR 4V 22U 1
C6305 AA10872R CAPACITOR CH 10V
0.1U
1
C6306 AA00968R CAPACITOR CH 6.3V
10U
1
C6307L AA01111R CAPACITOR CH 6.3V
1.0U
1
C6307R AA01111R CAPACITOR CH 6.3V
1.0U
1
C6308 AA01111R CAPACITOR CH 6.3V
1.0U
1
C6309 0893319 C.CAPACITOR CH 50V
1000P
1
C6311 AA00968R CAPACITOR CH 6.3V
10U
1
C6312 AA00968R CAPACITOR CH 6.3V
10U
1
C6313 AA01111R CAPACITOR CH 6.3V
1.0U
1
C6314 AA00968R CAPACITOR CH 6.3V
10U
1
C6315 AA00968R CAPACITOR CH 6.3V
10U
1
C6317 0893333 C.CAPACITOR CH 16V
0.01U
1
C6318 AD10891R CAPACITOR CH 6.3V
100U
1
C6319 AA01113R CAPACITOR CH 6.3V
2.2U
1
C6320 AA00968R CAPACITOR CH 6.3V
10U
1
C6322 AA01113R CAPACITOR CH 6.3V
2.2U
1
C6323 AD10891R CAPACITOR CH 6.3V
100U
1
C6324 0893333 C.CAPACITOR CH 16V
0.01U
1
C6327 AA10872R CAPACITOR CH 10V
0.1U
1
C6328 0893333 C.CAPACITOR CH 16V
0.01U
1
C6329 AA00966R CAPACITOR CH 6.3V
4.7U
1
C6330 AD10891R CAPACITOR CH 6.3V
100U
1
C6331 AA10872R CAPACITOR CH 10V
0.1U
1
C6332 0893333 C.CAPACITOR CH 16V
0.01U
1
C6333 0893333 C.CAPACITOR CH 16V
0.01U
1
C6334 AA10872R CAPACITOR CH 10V
0.1U
1
C8001 AA01111R CAPACITOR CH 6.3V
1.0U
1
C8002 AA01111R CAPACITOR CH 6.3V
1.0U
1
C8003 AA10872R CAPACITOR CH 10V
0.1U
1
C8005 AA10872R CAPACITOR CH 10V
0.1U
1
C8006 AA10872R CAPACITOR CH 10V
0.1U
1
C8011 0893319 C.CAPACITOR CH 50V
1000P
1 VDR-M95,75
C8051 AA00964R C.CAPACITOR 6.3V
2.2U
1
C8052 AA00964R C.CAPACITOR 6.3V
2.2U
1
C8061 AA00968R CAPACITOR CH 6.3V
10U
1
C8062 AA10872R CAPACITOR CH 10V
0.1U
1
CP5001 BM10631R COIL 1 VDR-M95,75,55
D6001 MA132K DIODE 1 MA3S132K
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
IC3701 CK43974R IC 1
IC5001 CK48771U IC 1 VDR-M95,75,55
IC6021 CK60151R IC 1 VDR-M95,75
IC6101 CK49891R IC 1 VDR-M95
IC6101 C0ABCB000051 IC 1 VDR-M75,55,53
IC6201 C0FBZJ000005 IC 1
IC6301 AN2903FJQ-V IC 1
IC8001 CK49881R IC 1
J7001 EA15291R PLUG 1
L3701 BA10577R COIL 1
L3702 BA10581R COIL 1
L6021 BA10149R COIL 1
L6101 0773004 COIL 1
L6301 BA10584R COIL 1
L6302 BA10577R COIL 1
L6303 BA10577R COIL 1
L6304 BA10577R COIL 1
L6305 BA10582R COIL 1
L6306 BA10577R COIL 1
LD8061 CC12281R DIODE 1
PG3701 EA15381R CONNECTOR 1
PG6001 EA14621R CONNECTOR 1
PG6002 EA15021R CONNECTOR 1
PG6003 EA15581R CONNECTOR 1
PG8001 EA15001R CONNECTOR 1
PG8002 EA15091R CONNECTOR 1
PG8003 EA15261R CONNECTOR 1
PG8004 EA15021R CONNECTOR 1 VDR-M95,75
PG8011 EA15411R CONNECTOR 1
PG8061 EZ10891 SD CONNECTOR 1
Q6001L CA14091R TRANSISTOR 1
Q6001R CA14091R TRANSISTOR 1
Q6002L CA14121R TRANSISTOR 1
Q6002R CA14121R TRANSISTOR 1
Q6003 CA14091R TRANSISTOR 1
Q6004 CA12871R TRANSISTOR 1
Q6021 CA12871R TRANSISTOR 1
Q6022 CA12891R TRANSISTOR 1
Q6023 CA12871R TRANSISTOR 1
Q6024 CA12891R TRANSISTOR 1
Q6027 CA14091R TRANSISTOR 1 VDR-M55,53
Q6028 CA14091R TRANSISTOR 1 VDR-M95,75
Q6029 CA14091R TRANSISTOR 1 VDR-M95,75
Q6030 CA14091R TRANSISTOR 1
Q6031 CA14091R TRANSISTOR 1 VDR-M95,75
Q6032 CA02111R TRANSISTOR 1
Q6101L CA14091R TRANSISTOR 1
Q6101R CA14091R TRANSISTOR 1
Q6102L CA12781R TRANSISTOR 1
Q6102R CA12781R TRANSISTOR 1
Q6103L CA14091R TRANSISTOR 1
Q6103R CA14091R TRANSISTOR 1
Q6104L CA14091R TRANSISTOR 1
Q6104R CA14091R TRANSISTOR 1
Q6105 CA14091R TRANSISTOR 1
Q6301 CA14101R TRANSISTOR 1
Q8001 CA14081R TRANSISTOR 1 VDR-M95,75
Q8002 CA12891R TRANSISTOR 1 VDR-M95,75
R3711 0790014 C.RESISTOR 1/16W
18
1
R3713 0790181 RESISTOR CHIP
1/16W 10
1
R3714 0790181 RESISTOR CHIP
1/16W 10
1
R3715 0790181 RESISTOR CHIP
1/16W 10
1
142
VDR-M95PP / VDR-M75PP / VDR-M55PP / VDR-M53PP
