6 Attach safety wire (accessory) to the ceiling or wall.
Attach the safety wire to the foundation or other parts of the building with sufficient strength
(minimum pull-out strength 196 N {44.06 lbf}).
Prepare screws according to the condition of the attachment position. Use the safety wire
(accessory), washer (accessory) and spring washer (accessory).
<When attached to the ceiling>
<When attached to the wall>
Ceiling
Recommended screw M4,
minimum pull-out strength
196 N {44.06 lbf}
Washer (accessory)
Spring washer (accessory)
Safety wire (accessory)
Washer
(accessory)
Recommended
screw M4,
minimum
pull-outstrength
196 N {44.06 lbf}
Foundation or
other parts of
the building with
sufficient strength
Spring washer
(accessory)
Safety wire
(accessory)
