LIST OF CONSUMPTION PARTS
MO1 Pan Motor
REF. NO. PART NAME LIFE
MO2 Tilt Motor
MO3 Cooling Fan
* This is working all the time.
Equal to power on time.
* Lens Motor itself is not supplied, but only
supplied as assembly.
M19 Lens (Focus Motor, Zoom Motor)
M6 Slip Ring
8 Those figures are just for a reference under 35 ˚C environmental temperature and not for a guarantee.
It changes depending on the actual environment/operating condition.
8 Part numbers of these consumption parts are described in Replacement Parts List on page 7-1.
2.16 million PRESET actions
2.16 million AUTOPAN revolutions
(19,200 hours as 32 sec per a turn)
50,000 hours
Each 3.7 million actions
10 million PRESET actions
10 million AUTOPAN revolutions
(88,888 hours as 32 sec per a turn)
